Bi2 Wall TR
ENGLISH
EN - 11
The number of rotations refers to the micrometric grub screw..
f. Openthescrewuntilendoftravel(4d).
The pre-adjustment has been set and won’t change in case of repeated opening and closure with
the Allen wrench.
2.7 - UNIT WITH 2-WAY VALVE WITH THERMOELECTRIC HEAD (Fig.12)
Theunitiscomposedofanautomaticvalvewiththermoelectricheadandofaholderequippedwithmicro-
metricadjustmentabletobalancetheloadlossesofthesystem.Insidetheunitarepresenttheinsulating
materialstobemountedonthevalveandontheholder.
2.8 - UNIT WITH 3-WAY DIVERTER VALVE WITH THERMOELECTRIC HEAD
(Fig.13)
Theunitiscomposedofa3-waydivertervalvewiththermoelectricheadandofaholderequippedwithmi-
crometricadjustmentabletobalancetheloadlossesofthesystem.Insidetheunitarepresenttheinsulating
materialstobemountedonthevalveandontheholder.
2.9 - FILLING THE SYSTEM
Duringstart-upofthesystem,makesurethattheholderonthewatersystemisopen.Inthecaseofabsence
ofpowersupplyandthethermalvalvehasalreadybeenpoweredpreviously,itwillbenecessarytousethe
specichoodtopressthevalvedisctoopenit.
2.10 - AIR EVACUATION DURING FILLING OF THE SYSTEM
a. Openalltheinterceptiondevicesofthesystem(manualorautomatic);
b.Startllingbyslowlyopeningthesystemwaterloadingvalve;
c. Workusingascrewdriverontheuppermostbatterybreather(28)(g.14).
d.Whenwaterstartscomingoutfromthebreathervalvesoftheappliance,closethemandkeeploading
untilthenominalvaluesenvisagedforthesystem.
Check for water tightness of the seals.
It is advised to repeat this operation after that the appliance has worked for a few hours and to
periodically check the system pressure.
2.11 - ELECTRICAL CONNECTION
Before carrying out any electrical connection, make sure that power supply is disconnected by the units
and that the systems to which the equipment must connect are compliant with the current standards.
Incaseyouwanttoproceedwithinstallationwithoutplug,proceedasdescribedbelow:
- Useacablewithaminimumsectionof3G0,75
- Useagroundcableatleast20mmlongerthantheactivewires.
- Connectthegroundconnectionwirestothecorrespondingterminal.
- Pullthewirestomakesuretheyareconnectedcorrectly,thenstopthemwiththespeciccabletie.
Forcorrectdimensioningoftheguards,pleaserefertovoltageandcurrentconsumptionindicatedonthe
labellocatedontheunit.
