A

400 600 800

A (mm) 906 1106 1306

B (mm) 380 380 380

C (mm) 129 129 129

D (mm) 150 150 150

A

B

D

C

ENGLISH

EN - 8

1.1 - OVERALL DIMENSIONS (Fig.A)

2 - INSTALLATION

2.1 - UNIT POSITIONING

Avoidinstallingtheunit:

- inpositionssubjecttodirectexpositiontosunrays;

- nexttosourcesofheat;

- inhumidenvironmentsandzoneswithprobablecontactwithwater;

- inenvironmentswithoilvapours

WARNING

A failure to apply the indicated standards, which may cause malfunctioning

of the equipment, relieves the company OLIMPIA SPLENDID from any form of

warranty and from possible damages caused to people, animals or property.

Makesurethat:

a. Thewallonwhichitisdesiredtoinstalltheunithasasuitablestructureandcapacity;

b. Theinvolvedzoneofthewallisnottravelledbypipelinesorpowerlines;

c. Theinvolvedwallisperfectlyat;

d. Thereisanareafreefromobstacleswhichmayhinderinletandoutletaircirculation;

e. Thewallforinstallationis,possibly,anexternalperimeterwallinordertoallowfordrainageof

condensation to the exterior.

 Ifitisnotpossible,pleaseenvisageasuitabledrainagelineforcondensation.

f. Incaseofhighinstallation,theairowisnottargeteddirectlyagainstpeople.

g. Theappliancemustbeinstalledinsuchapositionastoallowforeasyordinaryandextraordinary

maintenance,aswellasforeasyaccesstotheairbreathervalveswhichcanbereachedfrom

theuppergrilleoftheconnectionsside.
