2.9.4. Dismantling the exchanger

- Loosenthefourscrewsthatxtheexchanger(g.20ref.A);

- removethebatterywaterprobe;

- removetheexchanger(g.20ref.B);

- removethedrip-collectorextensionfromthecentraltray(g.20ref.C);

- ontheoppositesideremovetheplugonthecondensationevacuationhole(g.20ref.D);

- loosenthecentralcondensationcollectiontrayxingscrew(g.20ref.E),movethetrayandrestitonthe

 oppositesidesothatthexturemouthforthedrip-collectorextensioncomesoutofthestructure,and

 blockthetraywiththescrewpreviouslyremoved;

- re-insert the drip-collector extension and the plug on the opposite side;

- openthepre-cuthexagonalholesontherightsideinsulationandclosewithinsulationthehexagonalholes

on the left shoulder;

- rotatetheexchangermovingthexturestotheoppositeside,andreinsertitonthemachine(g.21);

- tightenallthexingscrewsoftheexchanger(g.22ref.A).

Whenalltheoperationsdescribedhavebeencompleted,remountallthecomponentsdismountedpre-

viouslyfollowingthedismountingoperationsintheoppositeorder.

2.10 - FILLING THE SYSTEM

Whenstartingupthesystem,makesurethatthehydraulicunitlockshieldisopen.Ifthereisnoelectric

powerandthethermo-valvehasalreadybeenpoweredusethespecialcaptopressthevalvestopperto

open it.

2.11 - EVACUATING AIR WHILE FILLING THE SYSTEM

- Open all the system interception devices (manual or automatic);

-Startthellingbyslowlyopeningthesystemwaterllingtap;

-FortheSLinstalledinaverticalposition,takeascrewdriverandactonthehighestbreatherofthebattery

 (g.23ref.A);

-ForSLRmodelswithheatingplateuseascrewdrivertoremovethebatterysidebreather(g.23ref.A)

 andthemanualbreatheroftheheatingplate(g.24ref.A).

- Whenwaterstartscomingoutofthebreathervalvesoftheappliance,closethemandcontinuellinguntil

reaching the nominal value for the system.

Checkthehydraulicsealofthegaskets.

Itisadvisabletorepeattheseoperationsaftertheappliancehasbeenrunningforafewhoursandperio-

dicallycheckthepressureofthesystem.

2.12 - MAINTENANCE

RoutinemaintenanceisindispensabletokeeptheBi2cooler-convectorinperfectworkingcondition,safe

and reliable over the years. This can be done every six months for some interventions and annually for

others,bytheTechnicalServiceAssistance,technicallyauthorisedandprepared,usingalwaysoriginal

spare parts.

2.13 - CLEANING THE OUTSIDE

Before every cleaning and maintenance intervention, disconnect the appliance

from the mains by switching o the master switch.
