Chapter 6 INFORMATION ABOUT EQUIPMENT
76
ES9455 MFP Specifications
Model name
ES9455 MFP
Type Desktop type
Original glass Fixed
Printing (copying) system Indirect electrophotographic method
Developing system 2-component magnetic brush developing
Fixing method Roller fusing
Photosensor type OPC
Original scanning system
Flat surface scanning system
(When the Reversing Automatic Document Feeder is installed: Fixed scanning system by
feeding the original)
Original scanning sensor Linear CCD sensor
Scanning light source LED
Resolution
Scanning 600 dpi x 600 dpi
Writing Color, Black-and-white (Grayscale): 600 dpi x 600 dpi, 5 bits
Acceptable originals Sheets, books
Acceptable original size Max. A3 or LD
Acceptable copy
paper size
Tray
A3, A4, A4-R, A5-R, B4, B5, B5-R, FOLIO, LD, LG, LT, LT-R, ST-R, COMP, 13"LG, 8.5"SQ, 8K, 16K,
16K-R
MPT
Paper size within 100 mm - 297 mm (3.94" - 11.69") (Length),
148 mm - 432 mm (5.83" - 17.01") (Width)
Acceptable copy
paper weight
Tray 60 - 163 g/m
2
(16 lb. Bond - 90 lb. Index)
MPT Continuous paper feed / Single paper feed: 60 - 209 g/m
2
(16 lb. Bond - 110 lb. Index)
Warm-up time Approx. 35 seconds
First copy time
(A4 or LT
portrait)
Black-and-white Approx. 8.2 seconds
Color Approx. 10.3 seconds
Continuous copy speed Refer to the Copying Guide.
Multiple copying Up to 999 sheets (digital key entry)
Excluded image
width
Black-and-white
Leading edge: 4.2 mm +2.8 mm - 1.2 mm (0.17" +0.11" -0.05"),
Trailing edge: 3.0 mm ±2.0 mm (0.12"±0.08"),
Both edges: 2.0 mm ±2.0 mm (0.08"±0.08")
Color
Leading edge: 5.0 mm +2.0 mm (0.20"±0.08"),
Trailing edge: 3.0 mm ±2.0 mm (0.12"±0.08"),
Both edges: 2.0 mm ±2.0 mm (0.08"±0.08")
Printer (Black-
and-white/Color)
Leading edge: 4.2 mm +2.8 mm - 1.2 mm (0.17" +0.11" -0.05"),
Trailing edge: 4.2 mm +1.2 mm -2.8 mm (0.17" +0.05" -0.11"),
Both edges: 4.2 mm ±2.0 mm (0.08"±0.08")
Reproduction
ratio
Actual size 100±0.5%
Zoom
25 - 400% (in 1% increments)
For the Reversing Automatic Document Feeder 25 - 200% (in 1% increments)
Paper supply
Tray Approx. 250 sheets (80 g/m
2
,
20 lb. Bond)
MPT Approx. 100 sheets (80 g/m
2
, 20 lb. Bond)
Stacker loading capacity Approx. 550 sheets (80 g/m
2
, 20 lb. Bond)
Toner density adjustment Magnetic auto-toner system + Pixel count system
Exposure control Automatic plus manual selection from 11 exposure step
USB interface USB 2.0 (Hi-Speed)
Environment (for normal use) Temperature: 10 ° - 30 °C (50 ° - 86 °F), Humidity: 20 - 85% (No Condensation)
Power requirements and Power
consumption
(including optional equipments)
AC 220-240 V±10%, 8 A (50/60 Hz): 1.6 kW or less
AC 120 V±10%, 12 A (50/60 Hz): 1.5 kW or less
Dimensions (equipment only)
575 mm (22.6") (W) x 590 mm (23.2") (D) x 662 mm (26.0") (H) (At 90 degrees of the control
panel angle)
575 mm (22.6") (W) x 707 mm (27.8") (D) x 662 mm (26.0") (H) (At 7 degrees of the control
panel angle)
Weight
Approx. 57 kg (125.7 lb.) (equipment including developer and drum)
Space occupied (equipment only) 964 mm (38") (W) x 707 mm (27.8") (D) (At 7 degrees of the control panel angle)
Storage capacity
When hard disk is installed: Max. 1000 sheets or until the memory is full (Oki’s own chart)
When hard disk is not installed: Until the memory is full
• This specication varies depending on the printing conditions and the environment.
• Specications and appearance are subject to change without notice in the interest of product improvement.
