Basic operations
- 79 -
Loading paper in Tray 1 (for B433)
This section explains the procedure for loading paper of standard sizes.
Here, the procedure of loading paper in Tray 1 of B433 is taken for example. If you are using B513 or if you
want to load paper in the optional expansion tray (Tray 2/3/4), please refer to "
Loading paper in Tray 1 (for B513)
or Tray 2/3/4 (Optional)
(P.80)".
For the paper that can be used, please refer to "
Applicable paper(P.74)" and "Paper applicable to each tray(P.78)".
To load paper of irregular sizes, please refer to "
Printing on irregular paper (Custom)(P.151)".
ļ For Tray 1, A5-sized paper can be loaded in either portrait or landscape orientation.
1
Pull out the lower paper cassette until it stops, and then lift it slightly upward to remove it.
2
Slide the blue part of the paper stopper to fit the length of the paper to be loaded. To load paper
of A4, Legal (13 inches), Legal (13.5 inches) or Legal (14 inches), pull the paper stopper out to
the rear side of the paper cassette.
Do not remove the cork from the metal plate.
3
Slide the blue part of the paper guide to fit the width of the paper to be loaded.
If the metal plate of the paper cassette is raised, press it down firmly until it clicks into place, and then insert it
into the printer. If the metal plate is inserted into the main unit while it is raised, malfunction may be caused.
