EN
ASSEMBLING AND MOUNTING
1
Assemble the two foot parts crosswise. Remove the four screws from the foot parts.
2
Use the four screws to mount the extension pole onto the feet. Then remove the height adjustment
ring.
3
Slide the stand cover over the extension pole onto the feet. Pull out the extension pole and secure
it by installing and fastening the height adjustment ring.
4
Attach the motor unit to the extension pole and secure it with the screws. Before secure it, the
height of the fan can be adjusted individually, by inserting / extracting the extension pole.
5
Remove the propeller nut and the plastic nut from the motor unit. Attach the rear guard to the
motor unit. The handle on the rear guard must point upwards and the dowel pins must t into the
intended holes.
6
Secure the rear guard with the plastic nut.
7
Slide the fan blade onto the motor shaft so that the pin locks to the groove. Secure the fan blade by
tightening the propeller nut onto the shaft.
8
Open the clips on the front guard. Hook the front guard onto the rear guard, thereby aligning the
screw holes at the bottom of the guards.
9
Install the screw and nut to lock the guards. Make sure all the clips are closed.
10
Place on a stable level surface. Set the desired angle and height.
OPERATION
11
Plug in the product.
12
Press the ON/OFF to switch on the fan. Press SPEED repeatedly to cycle through the fan speeds
(L=Low; M=Medium; H=High). Alternatively you can use the button
on the remote control to
select the speed. Press the button to turn on/o the product.
13
Press
button on the remote control for timed operation. Press the button repeatedly to set
the hours (1, 2, 4 hours) after which the fan should turn o.
14
Press the OSCILLATION / SWING knob to activate oscillation function.
Caution
• The product may only be connected to the mains once it has been completely assembled.
• The product must not be disassembled during operation, general care, cleaning and user
maintenance.
• The product may never be operated without the stand or in a horizontal position.
• Switch o and disconnect the product before adjusting height or desired angle.
• The guard must be completely closed when operating the product.
• During operation, do not put ngers or other objects in the guard.
• Unplug the product if it is not used for some time.
CHANGING BATTERIES
15
Open the battery compartment of the remote control. Insert 2 batteries (not included) of type
LR03 (AAA) observing the + and – polarities as indicated on the batteries and inside the battery
compartment. Close the battery compartment.
