30
EN
The undersigned, OCEANIC, declares that the radio equipment of the type Electric
heating ref. OCEAIFC1000W, OCEAIFC1400W, OCEAIFC1800W complies with
Directive 2014/53 / EU. The full text of the EU declaration of conformity is available at
the following internet address: www.oceanic.eu.
II. Technicial description
l Digital LCD screen
l Temperature adjustment via digital display
l Clock
l Weekly calendar
l 2 modes of use:
o Manual
o Automatic with weekly presetting
- 24h timer, custom setting.
- 7 different daily presets
- 6 orders pilot wire
l Frost protection function (Maintains temperature at 7ºC)
Model
Power
Voltage /
Frequency
Class
IP Class
OCEAIFC1000W
1000W
230V ~ 50Hz
Class II
IP24
OCEAIFC1400W
1400W
230V ~ 50Hz
Class II
IP24
OCEAIFC1800W
1800W
230V ~ 50Hz
Class II
IP24
III
．
Installation
1) Drill holes on the wall according to the instruction inside
Mur
Cheville
Crochet
Crochet
Vis
Radiateur
