Je bekijkt pagina 13 van 45
13
MENU: DMX INPUTS – A & B
The RDM10 processes two DMX Inputs. The source can either
be the DMX ports on the unit, or a network Universe via the RJ45
ports. For a network source, two Universes can be merged into
the Input.
SUB MENU
OPTIONS / VALUES
DESCRIPTION
Source
DMX, Network, SendValue
Select the source protocol
DMX
Source
DMX
RDM
Disable, Enable
Disable / Enable RDM traffic for this port
Network
Source
Network
Universe
1 – 32767
Select universe
Protocol
ArtNet, sACN
Select the protocol
FrameRate
10Hz, 15Hz, 20Hz, 25Hz, 30Hz,
35Hz, 40Hz
Select the desired frame rate
RDM
Disable, Enable
Disable / Enable RDM traffic for this port
Merge
OFF, HTP, LTP, Toggle
Select mode
Range
From: 1 – 512
To limit the DMX range, set the first address of the
DMX port
To: 1 – 512
To limit the DMX range, set the last address of the
DMX port
Offset Addr
OFF, 2-512
Offset start address, incoming channel X value is
sent on this port as channel X+Offset, Channels are
cut off if they exceed 512
SendValue
Source
SendValue
Select the source protocol
Value
0 - 255
Select universe
FrameRate
10Hz, 15Hz, 20Hz, 25Hz, 30Hz,
35Hz, 40Hz
Select the desired frame rate
Range
From: 1 – 512
To limit the DMX range, set the first address of the
DMX port
To: 1 – 512
To limit the DMX range, set the last address of the
DMX port
