51
Mellanox Technologies
a. Power numbers are provided for passive cables only. For board power numbers while using active cables, please add the outcome
of the following formula to the passive cables power numbers stated above:
Active_Module_Power
x N
umber_of_Modules
x 1.1
(efficiency factor)
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
d. Airflow is measured in wind tunnel.
e. The LFM number is based on a thermotical 1.5W module. The actual LFM requirement may change depending on the active
module thermal design.
7.2 MCX631105A[N/E/C]-GDAT Specifications
Physical Size: 3.79in. x 2.71in (96.30mm x 68.90mm)
Connector: Single QSFP28 Ethernet (copper and optical)
Protocol Support
Data Rate: Ethernet 1/10/25/50 Gb/s
Ethernet: 50GBASE-R2, 50GBASE-R4, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-
CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
PCI Express Gen 3.0/4.0: SERDES @ 16.0GT/s, 8 lanes (2.0 and 1.1 compatible)
Power Specifications
(a)
Voltage: 12V
Power Cable Type PCIe Gen 3.0 PCIe Gen 4.0
Typical Power
(b)
Passive Cables 11.72W 11.93W
Maximum Power Passive Cables 13.02W 13.23W
Voltage: 3.3Aux
Maximum current: 100mA
Maximum power available through QSFP28 port: 2.5W (each port)
Environmental
Temperature Operational 0°C to 55°C
Non-operational -40°C to 70°C
Humidity
90% relative humidity
(c)
Altitude (Operational) 3050m
Airflow Requirements @ 55C
(
d)
Hot Aisle - Heatsink to Port
Passive Cable TBD
Active 0.8 Cable TBD
Active 2.5W Cable TBD
