INSTALLATION MANUAL
INSTALLATION
9
Prepare the Hood
1 ] If present, remove all protective polyfilm from the hood and/or parts.
2 ] Using the tab, remove the grease filter from the hood by pushing it down and tilting filter out.
3 ] Remove both screws holding damper assembly to hood. Remove parts bag included with the
hood (captured behind the damper assembly). Remove damper assembly from inside the
hood and keep the screws for further use.
4 ] Remove the wiring cover (shaded part on illustration below) by sliding it out from the hood
and set it aside.
DAMPER
ASSEMBLY
SCREWS
