EN-5
6
Getting Started
6.1 Connection and Preparation
Connect the power adaptor to the back of the device and plug it into the power socket. Switch on the
device, and then it starts up.
Install the telescopic FM/DAB+ antenna for DAB and FM reception.
Install the rod Wi-Fi antenna for Wi-Fi reception.
Connecting to the network
For wired Ethernet
● Use an Ethernet cable (RJ45 jack) to connect the LAN ports on A571 and your network device. Check if
the light indicators on the network device are in the appropriate status.
For wireless Wi-Fi
● A broadband connection in combination with a wireless access point, router, or similar network device.
● The network device needs to support Wi-Fi (802.11 b/g/n) wireless connection.
Make sure you have set up the wireless network, and you have the WEP, WPA, or WPA2 security
password to activate the connection. You may also use the WPS (Wi-Fi Protected Setup) function
for easy pairing between the network device and A571. Check if the light indicators on the
network device are in the appropriate status.
Connecting the RCA line out
Use a standard RCA audio cable to connect from the line-out socket on the back of the device to the
external device.
Connecting the Coaxial out
It allows you to connect an audio cable from A561 to your own HiFi speaker system to enhance sound
performance.
Connecting the Optical out
It allows you to connect an optical cable from A561 to your own HiFi speaker system to enhance sound
performance.
6.2 General Device Functions
On the playing screen, rotate the volume knob or press / on the remote control to adjust the
volume. Switch off the sound by pressing on the remote control or device.
Press MODE on the device or MODE on the remote control to select modes.
Press and hold MENU on the device or MENU on the remote control to open the menu. Press MENU again
to close the menu and return to the playing screen.
On the menu, rotate the knob or press / on the remote control to move along the entries.
Press OK to confirm; press BACK on the device or on the remote control to step back.
Press on the device or on the remote control to switch to standby mode. The time, date, and any active
alarm times are displayed on the screen. Switch on with the same button.
When the album cover is displayed on the playing screen, press OK to view the full-screen size of the
picture. (This feature may need a software update. Contact us if required.)
Presets
Presets are stored on the radio and cannot be accessed from other radios.
To store an Internet radio preset, press and hold FAV on the device or Preset on the remote control. The
display shows the Save to preset screen. Select one of the 40 presets to save the currently playing station.
