All-in-One Video Controller VX6s
User Manual
3 Menu Operations
www.novastar.tech
8
Custom Resolution
Rotate the knob to set a custom width (increasing by even numbers), height and
refresh rate. After setting these parameters, rotate the knob to select Apply and
press the knob to apply the settings. If you do not press the knob to apply the
settings, the custom resolution will not take effect.
Figure 3-3 Custom resolution
3.3.2 Color Adjustment
The VX6s supports adjustment of the input color (namely image quality), including
brightness, contrast, saturation, hue and red/green/blue brightness (R/G/B).
Step 1 Choose Color Adjustment > HDMI 1 to enter the color adjustment page of HDMI 1
input source.
Step 2 Rotate the knob to select a parameter item you want to adjust and press the knob to
enter the parameter adjustment status. Then, rotate the knob to adjust the parameter
value. At last, press the knob again to confirm the adjustment.
Brightness: The brightness of the input source
Contrast: The ratio of the luminance of the brightest color (white) to that of the
darkest color (black)
Saturation: The degree of how deep or how light the colors of the input source
image is
Hue: The category of the colors of the input source image, namely red, green
and blue
R: The color cast of input source images. When the red parameter value is
greater, the image color is redder. The G and B have the same meaning.
Reset: Reset all parameters in the input color adjustment menu to the original
default values.
XI'AN NOVASTAR TECH CO., LTD.
