V-Can User Manual
3 Functionality
www.novastar.tech
9
Note:
If the resolution of the input source for mosaic is too high, go to Load Area to crop
the input source. The starting point of the cropping is the top left corner of the source
by default.
3.1.1.4 Adjust Input Color
V-Can allows you to adjust the brightness, contrast, hue and saturation of each signal
source accessed to the device.
Applicable Products
VX5s, VX6s, VX1000, VX600, VX400, J6, VS7, N9, VC6, VC10, CMS260
Notes
The NovaPro UHD Jr and VX16s do not support input color adjustment.
Operating Procedure
Step 1 Go to Programming > Input > Color to open the input color settings window as
shown in Figure 3-3.
Figure 3-3 Input color
Step 2 Select the desired input source from the drop-down list next to Source.
Step 3 Drag the slider, enter a value in the text box or click the up or down arrow next to the
text box to set a desired value for the selected color parameter.
Step 4 Click Apply or OK to complete the input color settings.
Click Reset to reset all the color parameters to defaults.
