TU40 Pro LED Playback Control Processor
User Manual
www.novastar.tech
4
Can be used for USB playback, firmware update and exporting
logs.
Supported image formats: *.jpg, *.jepg, *.bmp, *.png, *.gif
Supported video formats: **.mp4, *.mkv, *.ts, *.mov, *.avi, *.m4v,
*.flv, *.vob, *.webm, *.mpg
File systems supported: FAT32, NTFS, exFAT, FAT16
Output
Type
Qty
Description
1~20
20
RJ45 (1Gps)
OPT 1~2
2
10G OPT outputs, for fiber converting applications
AUDIO
1
3.5-mm audio output
Note: 3-conductor audio connectors are supported.
SPDIF
1
For digital fiber optic audio output
HDMI 1.3
1
Output monitoring for device debugging
Controls (CONTROL area)
Type
Qty
Description
ETHERNET
1
Max bandwidth: 1 Gbps
Connect to an external network or control software.
WIFI 1–2
2
Connect to Wi-Fi and Bluetooth antennas.
WIFI 3
1
Connect to a Wi-Fi Sta antenna.
SENSOR 1–2
2
Connect to light sensors or temperature and humidity sensors.
Phoenix
connector
(12 pins)
1
1x L: Left channel of output audio
1x R: Right channel of output audio
1x GND: Grounding
1x RS232 for connecting to the central control device
− Baud rate: 115200bps
− Data bits: 8, stop bits: 1, no parity, no flow control
1x IR-I: Infrared input
1x IR-O: Infrared output
1x VCC: 3.3 V power supply
1x GND: Grounding
1x RELAY
