NovaCLB-Screen Full-Screen Calibration System
User Manual
www.novastar.tech
3
Figure 1-4 System architecture for calibration of ultra-large screen – Using multiple serial ports
The controllers can be connected to the control computer via a single or multiple serial ports.
Via a single serial port: Connect the control computer via USB cable to the control port of the first controller
and cascade all the controllers via USB cables, as illustrated in Figure 1-3.
Via multiple serial ports: Connect the control computer to the control port of each controller, as illustrated in
as illustrated in Figure 1-4.
XI'AN NOVASTAR TECH CO.,LTD.
