SmartLCT User’s Manual
www.novastar.tech 5
3.2 Menu Bar/Tool Bar
Menu Bar/Tool Bar
Icon
Function
Edit
Undo（Ctrl＋Z）
Back to last step
Redo（Ctrl＋Y）
Cancel last step
Group
/
All the cabinets will be edited or moved together after
grouping.
Ungroup
/
Recover the grouped cabinets to single cabinets.
View
Zoom in
Zoom in the view of the cabinets on the screen.
Zoom out
Zoom out the view of the cabinets on the screen.
1:1
/
Display the cabinets with a scale of 1:1.
Zoom to fit
Adjust the cabinets to a viewable size on the screen.
Online status
/
Select this option to show the status of the receiving
cards connected to the Ethernet ports of the device.
(Green denotes online while gray offline.)
Cabinet info
/
Including “Sending card info”, “Port No.” and
“Receiving card info”.
The information of the option you selected will be
shown on the cabinets.
Auto connect
/
Select this option and the added cabinets will be
connected automatically.
Show grid
/
Select this option and the grid on screen area will be
visible.
Snap
/
Including “Snap to grid” and “Snap to cabinet edge”.
Select it, and when you moving a cabinet, the cabinet
will snap to the border of its nearest grid or cabinet
automatically.
View
Including “Front view” and “Back view” for changing
users’ view while looking at cabinet connections.
