KU20 LED Display Controller User Manual
www.novastar.tech
3
Inputs
Type
Qty
Description
HDMI IN
1
Resolutions
Max resolution: 1920×1200@60Hz
Min resolution: 800×600@60Hz
Max width/height
Max width: 3840 (3840×600@60Hz)
Max height: 2560 (800×2560@60Hz)
Frame rates
23.98 / 24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 / 59.94 / 60
/ 71.93 / 72 / 75 / 100 / 119.88 / 120 Hz
EDID management
Support standard resolutions, up to 1920×1080@60Hz.
Support custom input resolutions.
HDCP
HDCP 1.4 compliant, backwards compatible with HDCP
1.3.
Interlaced signal inputs
Not supported
Outputs
Type
Qty
Description
1–6
6
Gigabit Ethernet output ports. Support hot backup between Ethernet ports.
Max device load capacity: 3.9 million pixels
The maximum load capacity per Ethernet port is 659,722 pixels (8bit@60Hz).
For details, see 11 Ethernet Port Load Capacity.
Note:
The maximum load capacity is only achieved when the load width of a single
port is 128 pixels or more. If the load width is less than that, the load capacity
will be reduced accordingly, calculated as (128 - load width) × load height.
The customized KU20 program supports 10-bit output when it works with the
A10s Pro receiving card. If needed, please contact NovaStar for customization.
OPT
1
10G optical output port
HDMI LOOP
1
HDMI loop through. Up to 8 devices can be cabled in one loop.
SPDIF
1
A digital audio output (Reserved)
Controls
Type
Qty
Description
ETHERNET
2
Gigabit Ethernet control ports. Support TCP/IP protocol and star topology.
They have the same functions without priority and order, and can be connected to
VMP software. No switch or router is needed to deploy multiple devices on the
same LAN via device cascading as the network switching function is already built
in. Up to 20 KU20 devices can be cascaded.
AUX
1
An auxiliary port that connects to the central control device (RS232) (Reserved)
Power
100-240V~, 50/60Hz,
1.5A
1
An AC power input connector and switch
