2. OVERVIEW | 9
2
OVERVIEW
ORGAN SECTION
The dedicated Organ section, with its two independent Layers, features
physical drawbars accompanied by LED graphs for hands-on control
and ease of use.
The B3 model is based on the analysis of the signals generated by
each of the 91 spinning discs inside several original instruments,
and painstaking work on understanding exactly how all the original
components interact with each other. The virtual circuitry reacts not only
to the settings on the panel but also in response to your playing. The
Stage 4 faithfully reproduces the important foldback and energy robbing
characteristics; the latter will produce the gentle compression effect that
makes those lovely smears a joy to play. The three tonewheel modes
allow for switching from a clean, factory new instrument to a worn and
battered workhorse. The B3 Bass mode allows for split or dual keyboard
setups with the dedicated bass drawbars for the left hand or pedals.
We have also created carefully modelled emulations of two of the most
famous transistor organs from the 1960’s; the Vox Continental and the
Farf (Farfisa) Compact. Alongside the organs themselves, the Nord
Stage 4 features a rotary speaker simulation derived from the Nord
C2D. Incorporating the acoustic variations that occur as a physical
rotating speaker spreads the sound around in a room, they bring the
organ sounds to life with remarkable realism. All Nord Stage 4 models
feature physical drawbars coupled with LED graphs.
Finally, there are two distinct Pipe Organ models including a “Principal”
Pipe model with two variations, delivering a wide range of versatile
pipe/church organ sounds.
This section is described in detail in the Organ chapter, beginning on
page 18.
PIANO SECTION
The Nord Stage 4 Piano section, with its two independent Layers,
delivers a stunning range of piano and keyboard sounds. Piano sounds
are divided into six different types including both classic Grand, Upright
and Electric pianos as well as Clavinet, Harpsichords, Digital pianos and
Miscellaneous sounds.
NORD PIANO LIBRARY
The Nord Stage 4 benefits from the sounds found in the ever-growing
Nord Piano Library. We spend a lot of time and effort on expanding the
palette of available sounds, ranging from state-of-the-art concert grand
pianos to characterful uprights, historical instruments, electric pianos
and more.
New sounds are regularly made available free of charge on the
www.nordkeyboards.com website.
STRING RESONANCE
String resonance is a physical phenomenon which occurs inside every
acoustic piano when strings, or parts of strings, resonate at their
fundamental or harmonic frequencies as other strings are being played.
When String Resonance is turned on, played notes will affect each other
to reproduce the acoustic interactions that occur inside an acoustic
grand or upright piano.
NORD TRIPLE PEDAL
The Nord Stage 4 is compatible with the Nord Triple Pedals which
unlock additional functionality within the Piano section.
The right pedal is the sustain pedal. When operated, all notes being
played will sustain until the pedal is released again. It also adds dynamic
control of the mechanical “pedal noise” and enables dynamic “half-
pedaling” techniques.
ORGAN SECTION PIANO SECTION PROGRAM SYNTH/EXTERN SECTION LAYER EFFECTS
Pearl Upright L
Melody Pad
2:53
B3 Flute 2
1:27
E:26
Sweet Layers
Multi Saw 8ve
WAVE
2(6)
MULTI
4.5
ANALOG
DETUNE:
TYPE CAT
OSC WAVEFORM
