60 | NORD STAGE 4 USER MANUAL OS V1.4X
5 - ROTOR PEDAL
TYPE
This allows you to change the type/polarity of a switch pedal connected
to control ROTOR PEDAL input, in case the functionality of a connected
pedal is reversed. On the Nord Stage 4 Compact model, this can also
be set to Half Moon Switch.
Range: Nord SP-1 (Default), Normally Open, Normally Closed, Half
Moon Switch (only on Compact model)
FUNC (FUNCTION)
This allows for changing the functionality of a switch pedal connected
to the ROTOR PEDAL input on the Nord Stage 4. With Rotor Toggle the
fast/slow rotor speed is switched with each press on the pedal, like
an on/off switch pedal. With Rotor Hold the Rotor Speed is fast for as
long as the pedal is down and reverts back to slow when the pedal is
released.
Range: Rotor Toggle (default), Rotor Hold
6 - FOOT SWITCH
TYPE
The Foot Switch jack on the Nord Stage 4 accepts a variety of different
pedals, with either one or two buttons/switches. Set the Type parameter
according to the connected model.
If you are unsure of the polarity of the pedal, simply check whether the
chosen functionality works as expected, if not select the other polarity
(Open or Closed).
i The Nord SP-2 pedal, and other continuous type pedals, are not
compatible with the Foot Switch jack.
Range: Single Open, Single Closed, Dual Open, Dual Closed
SW A (SWITCH A)
The Switch A parameter determines the function of an attached single
pedal, or the first switch of a dual pedal.
Range: User Assigned, Layer Scene Hold, Layer Scene Toggle, Pump,
Mst Clk Tap, Synth Vibrato, Program Up, Program Down, Rotor Hold,
Rotor Toggle
SW B (SWITCH B)
The Swtich B parameter determines the function of the second switch of
a dual pedal and has no effect when a single pedal is connected.
Range: User Assigned, Layer Scene Hold, Layer Scene Toggle, Pump,
Mst Clk Tap, Synth Vibrato, Program Up, Program Down, Rotor Hold,
Rotor Toggle
7 - PEDAL OVERVIEW
The Pedal Overview page shows all current pedal settings, and allows
for changing any of these settings – from a single page.
• Use the Page buttons to focus a Pedal setting and the dial to change
its value. In the example picture, the middle pedal for the Triple Pedal
has been selected and is set to Sostenuto.
• Non-connected pedals are displayed with a dash “–” but its current
setting is shown, and can be changed, when selected using the Page
buttons. In the example there is no Swell pedal connected.
• Foot Switch is abbreviated to “Ft.Sw”, with settings for Switch A and
B displayed to its right. In the example A is set to Master Clock Tap
and B set to Pump.
MIDI MENU
Hold SHIFT and press MIDI (Program 7) to access the MIDI menu
settings. Use the PAGE 3 and 4 buttons to navigate between pages.
The PROGRAM Dial is used to change settings and soft buttons are
used to access additional settings where applicable. When you are
done, press EXIT (Shift) to exit the menu.
1 - LOCAL CONTROL
MIDI Local control determines if the Nord Stage 4 keyboard and front
panel controls should control internal instruments and programs or only
transmit MIDI. Local On is the normal “play mode”. In Local Off mode,
front panel and keyboard actions are transmitted via MIDI only.
Range: On (Default), Off
i Local Control always defaults back to “On” when the Nord Stage 4
is powered on.
2 - GLOBAL CHANNEL / AUX KB
GLOBAL CHANNEL
This sets the transmitting and receiving MIDI channel for the Global
Channel. The Global Channel transmits all keyboard, pedal and panel
actions as MIDI signals. It can also be used as a receiving channel with
full control of the entire Stage 4.
Range: 1-16, Off (Default 1)
AUX KEYBOARD CHANNEL
This sets the MIDI channel for receiving MIDI from an external keyboard
when using Aux KB mode - see page 43.
Range: 1-16, Off (Default 16)
3 - ORGAN CHANNEL
Use this setting to determine the MIDI channel for controlling the two
ROTOR TOG
MCLK TAP
PUMP
-
SOSTENUTO
SUSTAIN
UNA CORDA
CTRL+SWL
CTRL
PEDAL OVERVIEW 7/7
SUST/TRIPLE
SWELL
ROTOR
FT.SW
