26 | NORD PIANO 6 USER MANUAL OS V1.1X
8
MIDI
MIDI FUNCTIONS
The Nord Piano 6 can be used as a master keyboard to control other
hardware units or software sound sources, and it is also possible to
control the Nord Piano 6 from a separate keyboard or MIDI device.
MIDI CHANNEL
The MIDI channel is used both for transmitting and receiving MIDI
information, at the same time. It allows for external control over every
aspect of the Nord Piano 6 – much like playing its own keyboard – and
is used for sending keyboard, pedal and panel actions to another MIDI
device or sequencer.
l MIDI messages are transmitted and received on both the USB and
MIDI In/Out connections simultaneously.
RECORDING A NORD PIANO 6 PERFORMANCE
TO A MIDI SEQUENCER OR DAW
Here is how to record a Nord Piano 6 performance including any pedal
actions and parameter adjustments to a DAW or MIDI sequencer.
1 Set the DAW or sequencer to use the Nord Piano 6 USB MIDI
driver, if connected through USB, or the appropriate MIDI interface
if connected through the 5-pin MIDI connectors.
2 Set the DAW or sequencer track to route back incoming MIDI on
the MIDI channel set on the Nord Piano 6.
3 Set Local in the System menu to Off on the Nord Piano 6.
4 Select the Program on the Nord Piano 6 that you wish to use.
5 Start the recording on the sequencer.
i If a Transpose value is set, either by the panel Transpose function
or the Global Transpose setting in the System menu, its effect on
MIDI depends on the “Transpose MIDI at” setting – see page 29.
MIDI MESSAGES
The following MIDI messages can be transmitted and received by the
Nord Piano 6:
NOTE ON/OFF
• Note On and Note Off messages including velocity are transmitted
and received.
CONTROLLERS
• From the System menu it can be determined whether the Nord Piano
6 should transmit and/or receive Control Change messages, see page
30.
• If a Control/Expression pedal is connected to the Control/Volume
Pedal Input, this is transmitted and received as Controller 11
(Expression).
• If a sustain pedal is connected to the Sustain Pedal Input, this – as
well as the right pedal of a Nord Triple Pedal – is transmitted and
received as Controller 64 (Sustain Pedal).
• Almost all other controls (knobs and buttons) on the front panel are
also transmitted and received as Control Change messages. This can
be used for recording front panel actions into a MIDI sequencer. For a
full list of MIDI Control Change messages, refer to page 33.
PROGRAM CHANGE
Loading a Program or Live Program will send a Program Change
message on the Global MIDI channel, each content type identified by its
Bank MSB value. Conversely, incoming Program Change messages will
select the corresponding content on the Nord Piano 6.
One MIDI program bank encompasses three banks of 36 programs
each on the Nord Piano 6, with program numbers 1-108 being used.
The message consists of three parts, as defined in the table below:
Program Live
Bank MSB (CC# 0) 0 1
Bank LSB (CC# 32) 0-5 0
Program Change 1-108 1-6
i A Program Change message that reaches the Nord Piano 6
unaccompanied by Bank Select messages will take effect in the
currently selected Program or Live bank.
In the System Menu, you can select if the Nord Piano 6 should send
and/or receive Program Change messages on the currently set MIDI
channel. See page 29 for further details.
LOCAL CONTROL ON/OFF
If Local Control is set to Off, the keyboard and panel on the Nord Piano
6 are “disconnected” from its sound engines. Use the Off setting when
the instrument is set up in a MIDI loop, for instance when using it in
conjunction with a DAW or seqencer. Local Control On/Off is set in the
System menu, which is described on page 29.
