2. OVERVIEW | 7
2
OVERVIEW
THE NORD ORGAN 3 PANEL
The Nord Organ 3 front panel is laid out with all related features and
controls logically grouped in individual sections, and in correspondence
with the original reference instruments whenever possible. Let’s have a
quick look:
MASTER LEVEL
At the far left is the Master Level control for setting the overall volume
level for all outputs, including the High Level and Aux outputs.
PROGRAM MODE (PROG MODE)
This important control determines whether the physical positions of the
drawbars are used for all drawbar sets – referred to as Panel Mode – or
whether the central drawbar sets use the settings stored with a Program
– referred to as Program Mode. In Program mode, drawbar settings are
indicated with single LEDs being lit at the endpoint of a drawbar setting.
A number of other panel functions, such as B3 Percussion, Vibrato/
Chorus and more are also included in the Panel and Program modes
respectively. Read more about this setting on page 13.
ORGAN AND BASS MODEL
The Nord Organ 3 features five distinct Organ Models and five Bass
Models, the latter of which come with an alternate option, providing
useful and creative variations on each Bass Model setting. Organ
and Bass Models are selected individually, allowing for matching the
Organ and Bass registers as on the original instruments, or for free
combinations of Organ and Bass sounds.
The Organ and Bass Models are described further on page 14.
ROTARY AND AMP SECTION
This is where the Rotary Speaker simulation and other amplifier
simulations are activated. The Rotary Speaker comes with additional
settings for Mic Positions and Drive Type, allowing for a wide range of
variations in sound and character.
Read more about these features on page 18.
PROGRAM AREA
The central Program area is where programs are navigated, stored and
loaded, and is also where you will find the System and Sound menus,
containing important settings related to areas such as pedal and MIDI
functionality, output routing options, sound and character of the Rotary
Speaker and more.
The Program area is covered in detail, beginning on page 20.
ADDITIONAL EFFECTS
In addition to the Rotary and Amp options a selection of additional
effects are available:
The Modulation unit provides essential modulation effects such as
Tremolo, Chorus and Phaser – modelled after legendary stomp boxes
and effects units.
ORGAN/BASS MODEL ROTARY SPEAKER/AMP SIM
PROGRAM
ADDITIONAL EFFECTS
PRESETS
MASTER
LEVEL
PROG
MODE
DRAWBAR A/B FOCUS
ROTOR SPEED CONTROL
B3 PERCUSSIONBASS PEDAL DRAWBARS
UPPER MANUAL DRAWBARS LOWER MANUAL DRAWBARS
B3 Panel
