NORD MODULAR G2 V1.4x 6. Working in the Editor: Morph groups
Page 93
A
SSIGN
PARAMETERS
TO
A
M
ORPH
GROUP
1. Click on any of the Morph group knobs in the toolbar to
select it. The white frame moves to the selected Morph
group and the Morph group knob turns red. Then Ctrl-
click on the knob, button or slider you wish to assign to
the selected Morph group. Alternatively, right-click on the
module parameter and select ‘Morph assign’. The color of
the selected parameter will now change to red to indicate
it’s been assigned to the selected Morph group.
2. Every parameter assigned to a Morph group should also
be given a Morph range. Place the cursor on the knob that
you assigned to the Morph group. Hold down the Ctrl key
and Click-drag the cursor as if you were turning the knob.
A red sector will appear, indicating the Morph range. The
range will also appear in a yellow hintbox next to the parameter. The initial Morph value is where the
black line is on the knob. Note that if you assign buttons to a Morph group, the Morph range
will always be fixed at the maximum range.
3. Turning the Morph group knob in the toolbar will now control the morphed parameter within the
selected range. Note that the morphed knob(s) in the module(s) won’t change visually.
4. If you want to assign parameters to another Morph group,
click another Morph group knob in the Toolbar and repeat
the procedure from step 1. Any parameters assigned to
other Morph groups will now turn blue to indicate they are
morphed from another source.
You can assign each Morph
group knob to any of the
predefined controls
M
ODWHEEL
, K
EYBOARD
V
ELOCITY
, K
EYBOARD
N
OTE
V
ALUES
,
A
FTERTOUCH
, C
ONTROL
P
EDAL
, S
USTAIN
P
EDAL
, P
ITCH
S
TICK
, G2X G
LOBAL
W
HEELS
or to
A
SSIGNABLE
K
NOBS
on the front panel. If you want to assign a Morph group only to an A
SSIGNABLE
K
NOB
instead of the predefined control source, simply click the Group button below the Morph group
knob in the Toolbar. Then, right-click the Morph group knob and select Assign|Page X|Knob. The
caption above the Mprph knobs can also be renamed by right-clicking and selecting ‘Edit name’. You can
also assign the Morph group knob to a
MIDI
controller by right-clicking and selecting
MIDI
Controller|Assign.
D
EASSIGN
PARAMETERS
FROM
A
M
ORPH
GROUP
To deassign a parameter from a Morph group, right-click on the parameter and deselect ‘Morph assign’
in the popup.
