NORD MODULAR G2 V1.4x 5. The Editor application: Basic module functions
Page 71
C
OLOR
The six available cable colors are identified by their names.
• Audio cables are red
• Control cables are blue
• Logic cables are yellow
• Logic cables at full bandwidth are orange
• User1 cables are green
• User2 cables are purple
You can choose another color (name) for a cable in this popup. Changing cable type will not affect the
functionality in any way, just the appearance. Cables in a serial cable chain will always have the same color.
Cables in a branch connection may have different colors. It’s possible to show and hide cables of
different colors in the Patch to make Patching easier. See “Visible cables” on page 62.
D
ELETE
Deletes the entire serial cable chain that the connection is part of. If you want to delete a complete branch
connection, this must be done from the cable origin of the branch.
D
ELETE
U
NUSED
C
ABLES
Deletes all non-functional input-to-input connections (white cables) in the Patch.
BASIC MODULE FUNCTIONS
C
ABLES
AND
CONNECTORS
Almost every module and nearly every function of a module can be Patched to other modules and
functions, using virtual cables. Each module has one or more connectors (except for some modules in
the
MIDI
module group which have no connectors). These connectors come in two different shapes:
circular inputs and square outputs, and three different variants: red audio, blue control and yellow logic
connectors. Most of the modules share the same basic layout, with the audio input connector(s) to the
top right and the audio output connector(s) to the bottom right.
M
ODULE
OUTPUT
SAMPLE
RATE
Modules can process and output signals at two sample rates: 96kHz and 24kHz.
The fast 96kHz sample rate is used for processing audio signals. Modules that generate audio signals, like
Oscillators, all generate the audio at a 96kHz sample rate. You can tell the sample rate of an output signal
by the color of the output connector, if it is red or orange the sample rate of the output signal is 96kHz.
Cables connected to this output will inherit this color. Note that you can change the color of the cables
