3. Working with the synth: System Functions section NORD MODULAR G2 V1.4x
Page 26
SYSTEM FUNCTIONS SECTION
M
ASTER
L
EVEL
The M
ASTER
L
EVEL
knob controls the output level of all four O
UT
jacks and the
H
EADPHONES
output. Use this knob to set the overall volume level of your instrument or
set the sound level when using headphones.
Tip! The Master Level knob does not send or receive any
MIDI
CC
# information, but is only
used to control the entire instrument’s output level. To affect the volume of an individual Patch through
MIDI
(.e.g. from a sequencer track), you can use
MIDI
CC
#7, which is hardwired to the Patch Gain knobs
in the respective Slots (see more about this on “Patch Level” on page 62).
MIDI
LED
The
MIDI
LED
indicates incoming
MIDI
Note,
MIDI
CC
# and
MIDI
SYSEX
messages on any
MIDI
channel.
MIDI
messages on any of the Slot’s
MIDI
Channels and/or the Global
MIDI
Channel are indicated by long
LED
blinks. Messages on other
MIDI
Channels are indicated by
short
LED
blinks. Long
LED
blinks means that there should most probably be sound, and
short
LED
blinks mean that there is
MIDI
information received but ignored, as this information is not in
MIDI
channels the Slots are ‘listening to’.
M
IC
L
EVEL
The M
IC
L
EVEL
knob controls the
XLR
microphone input preamp level. Below the M
IC
L
EVEL
knob are three
LEDS
which show the input level of the dynamic microphone
connected to the XLR I
NPUT
on the rear panel. If you don’t use a mic, the L
EVEL
LEDS
will indicate the input level of the line level signal routed to the I
N
1 input instead. Note that
the M
IC
L
EVEL
knob only affects the XLR I
NPUT
- not the I
N
1 input.
S
YSTEM
, P
ATCH
AND
S
TORE
BUTTONS
Above the M
AIN
D
ISPLAY
are the S
YSTEM
(see “Edit System Settings” on
page 29) and P
ATCH
(see “Acessing (Edit) any Parameter in a Patch” on page 37)
buttons which can be used to enter all system and Patch related menus. The
S
TORE
button (see “Store a Patch” on page 40 and “Storing a Performance” on
page 50) is used for storing Patches and Performances.
N
AVIGATOR
BUTTONS
, R
OTARY
D
IAL
AND
M
AIN
D
ISPLAY
Below the M
ASTER
L
EVEL
knob is a set of four buttons, the
N
AVIGATOR
buttons. These are used to navigate in the M
AIN
D
ISPLAY
and to select different functions. Below the
N
AVIGATOR
buttons is the R
OTARY
D
IAL
. With the R
OTARY
D
IAL
you can select Patches and Performances, enter various
kind of data etc.
Note that the functions for the N
AVIGATION
BUTTONS
, the
R
OTARY
D
IAL
and the M
AIN
D
ISPLAY
will change when the G2
is set to a different mode. Modes can be changed by pressing
either the S
YSTEM
, the P
ATCH
, the S
TORE
or the P
ERFORMANCE
M
ODE
button.
L
OAD
P
ATCH
Press this button when you want to load a selected Patch or Performance into the focused
Slot/Slots (see “Search for and load a Patch” on page 36 and “Load a new Performance from
the internal memory” on page 48).
