NORD MODULAR G2 V1.4x 13. Module reference: Mixer group
Page 217
C
HANNEL
M
UTE
BUTTONS
Some mixers feature Channel Mute buttons to mute the inputs. A blue Channel Mute
button means that the channel is enabled. These Channel Mute buttons are basically
Name buttons, meaning that they can be labelled with your own text for better overview, these names
will show up in the G2 frontpanel displays when the associated mixerknob is assigned to a panel knob.
Right-click on a Channel Mute button and select ‘Edit name’. Type in the new name and press Enter.
Note that the name cannot be longer than 7 characters because of the size of the A
SSIGNABLE
D
ISPLAYS
on the synth. The Channel Mute buttons cannot be assigned to a Morph Group.
M
IX
1-1A
This mixer has one D
YNAMIC
C
ONTROL
/A
UDIO
signal input, a chain input and one output. The mixer
has a Channel Mute button for enabling/disabling the
input. The Channel Mute button can be labelled. See also "Common Mixer parameters”.
M
IX
1-1S
This mixer has stereo D
YNAMIC
C
ONTROL
/A
UDIO
signal inputs, stereo chain inputs and stereo outputs.
The mixer has a Channel Mute button for enabling/
disabling the inputs. The Channel Mute button can be labelled. See also "Common Mixer parameters”.
M
IX
2-1A
This mixer has two D
YNAMIC
C
ONTROL
/A
UDIO
signal inputs and one output. Each input is equipped
with a separate attenuation control. The mixer has a
Channel Mute button per channel for enabling/disabling the inputs. TheChannel Mute buttons can be
labelled. See also "Common Mixer parameters”.
M
IX
2-1B
This mixer has two D
YNAMIC
C
ONTROL
/A
UDIO
signal inputs and one output. Each input is equipped
with a separate attenuation control. Each channel also
has a separate control for inverting the input signal.
I
NV
Click the Inv button(s) to invert the input signal(s) polarity, i.e. phase shift them 180 degrees. See also
"Common Mixer parameters”.
Tip! The Inv button can be conveniently used if a control signal must be subtracted from another signal
instead of added, or if an audio signal must be mixed in ‘anti-phase’ with another audio signal.
M
IX
4-1A
This mixer has four D
YNAMIC
C
ONTROL
/A
UDIO
signal inputs and one output. See also "Common Mixer
parameters”.
