13. Module reference: Random group NORD MODULAR G2 V1.4x
Page 196
controls to fine-tune the random wave shapes or sequence of random values. The rate can be easily
modulated by applying a varying control signal to the Pitch input that has the modulation depth knob.
R
ND
C
LK
A
The clocked random step module produces a new
random value each time it receives a trigger pulse on its
Clk input. Use the Dice button to 'randomize' the
module manually, instead of using the Clk input.
R
ND
C
LK
B
The modulatable clocked random signal module
produces a new random value each time it receives a
trigger pulse on its Clk input. Using the Rst input and the
Seed input will 'randomize' the module to a position in
the pseudorandom sequence that is set with the value on the Seed input. Step settings can be modulated
by a control signal on its input, setting the amount of modulation is done with the modulation depth
knob.
R
ND
T
RIG
The random state or random pulse module produces a
yellow pulse or gate output signal at a state that is either
a logic
HIGH
or logic
LOW
. The output signal can be used
directly to trigger yellow Trigger or Gate inputs. Note that when using the output signal as an analog (to
a blue or red input) control signal, the output alternates between a logic
LOW
or 0 units for the
OFF
state
and a logic
HIGH
or +64 units for the
ON
state.
For every new pulse it is decided if it is passed to the output or not, making the output signal equal in
ON
duration to the
ON
duration of the input pulse signal. This means that if gate signals of different lengths
are used to clock this module, the length of the current gate signal is left unaltered if the module decides
to 'pass' this current clocking gate signal to the output of the module.
R
ND
P
ATTERN
The RndPattern generator produces short repeating
sequences of either random values or random state
signals. Length of the sequences can be set by the Length
control. This module is similar in its core to the
modulatable clocked random signal module. The difference is that this module has an internal clock rate
divider prepatched internally to the Rst input. There are over 32000 different patterns with a maximum
length of 128 steps, presettable by the A and B pattern and the Length controls.
By connecting control signals to the A and B inputs the control signal values will set the pattern to be
played. These control values are added to the values set by the A and B controls, expanding the pattern
range to many millions of possible patterns.
Two different types of pattern are available, one based on the Character Type 1 random sequence and
one based on the RndTrig random sequence. If the output wave shape is set to random trigger mode, the
clocking gate signal will pass through to the output in the same way as descibed by the RndTrig module,
though with a signal alternating between -64 and +64 units.
