NORD MODULAR G2 V1.4x 13. Module reference: LFO group
Page 189
O
UTPUT
The signal output on the LFO. Signal: B
IPOLAR
OR
U
NIPOLAR
depending on Output Type
selection (see above).
L
FO
A
LFO A produces one of six different control signals. The
rate of the LFO can be modulated from external sources.
W
AVEFORMS
Select waveform with the radio buttons. The waveforms are: Sine, Triangle, Sawtooth, Square, Random
Steps and Random. The Random Steps signal is “colored" meaning that the effect is more gentle than a
true random signal. It contains less radical differences between adjacent values. The Random signal is a
smooth random control signal. See also "Common LFO parameters”.
L
FO
B
LFO B generates one of four different control signals.
The phase of the signal can be controlled and
modulated. The rate of the LFO can be modulated by a
modulation source and the keyboard. The wave cycle can
also be forced to restart via the Rst input. See also
"Common LFO parameters”.
L
FO
C
This LFO produces one of six selectable waveforms.
The rate of the LFO can be modulated. LfoE has the
same wave shapes as LfoA but uses less Patch Load
because of the drop-down waveform selector. See also "Common LFO parameters”.
L
FO
S
HP
A
LfoShpA generates one of six different shapable control
signals. The shape and phase of the signal can be
controlled and modulated. The rate of the LFO can be
modulated by a modulation source and the keyboard.
The wave cycle can also be forced to restart via the Rst
input. It’s also possible to alter the rate and “direction”
of the signal via the Dir input (see below).
