13. Module reference: Oscillator group NORD MODULAR G2 V1.4x
Page 172
OSCILLATOR GROUP
The Nord Modular G2 oscillators produce continuous waveforms with a certain pitch and an amplitude
swing that is between -64 and +64 units. If you connect an oscillator output to a mix bus, it will generate
a constant sound - just as you would expect. If you want the behaviour of a traditional synthesizer, i.e. to
generate sound only when you play on the keyboard, patch the output of the oscillator to the audio signal
input of an envelope generator. Then, patch the audio signal output of the envelope generator to an
Output module.
C
OMMON
O
SCILLATOR
PARAMETERS
W
AVEFORM
RADIO
BUTTONS
Some oscillators feature waveform selectors of radio-button type. All waveforms
instantly available after selection, which means that you can switch waveform
without any interruption. This radio-button control can be assigned to a frontpanel knob to instantly
select waveforms on the frontpanel.
W
AVEFORM
DROP
-
DOWN
SELECTORS
Some oscillators feature drop-down waveform selectors. The different waveforms of these
oscillators are not instantly available as in the “radio button” oscillators described above.
Waveforms from the drop-down menu must be preselected in the Editor program. Selecting another
waveform in the Editor will force the G2 to optimize the
DSP
s and will cause a brief moment of silence.
The advantage of this is that these oscillators use less Patch Load.
Note that Oscillators with drop-down waveform selectors will use the preselected waveform in all 8
Variations. If you want different waveforms in different Variations, use oscillators with radio buttons
instead.
W
AVEFORM
DROP
-
DOWN
SELECTORS
WITH
GRAPHS
The Shape Oscillators have drop-down waveform selectors with a graphical display of the wave
shape that shows how the waveform changes when tweaking the Shape knob. Waveforms from
the drop-down menu must be preselected in the Editor program. Selecting another waveform
in the Editor will force the G2 to optimize the
DSP
s and will cause a brief moment of silence. The
advantage of this is that these oscillators use less Patch Load.
Note that Oscillators with drop-down waveform selectors will use the preselected waveform in all 8
Variations. If you want different waveforms in different Variations, use oscillators with radio buttons
instead.
S
EMI
/F
REQ
/F
AC
/P
ART
SCROLL
BUTTON
Click this button to switch the frequency control modes between Semitone, Frequency, Partial and
Factor mode. The respective mode is also shown in the Display box. The following ranges and
characteristics are valid for the different modes:
• Semitone range: -64 to + 64 (C-1 to G9) relative to the input value on an unattenuated
Pitch input on the oscillator module. If the KBT button is on, the Semitone value is
relative to the note played on the keyboard (or received via MIDI). If KBT is not active and no Pitch
modulation is present, the factor value is relative to the note E4.
• Frequency range: 8.1758 Hz to 12.55 kHz if KBT is not active and no Pitch modula-
tion is present.
