MIDI Implementation Page 93
System Exclusive Implementation
Numbers are in decimal except when preceded by a “$” character, in which case they are in hexadecimal
format.
General Message format
Patch Dumps
This message contains the actual Patch Dump. One complete message contains the data for one Patch.
It is transmitted from the Nord Lead 2 in one of two cases:
▼ When a Patch Dump is initiated from the front panel.
▼ When a valid Patch Dump Request message has been received.
This message should be sent to the Nord Lead 2 when you want to replace a Patch currently in the instru-
ment, with a new one.
The Message Type and Message Specification bytes in the Sys Ex message contains information about
from which location the Patch Dump was sent. When a Patch is sent to the Nord Lead 2, it will end up in
this location.
▼ If the Sys Ex data for a complete Bank is sent (using the “Dump All” command), the Program location
within the Bank is stored for each Patch. When any or all of these Patches are sent back to a Nord Lead
2, they will be stored at their original Program Location, but in the Bank that is currently selected on the
Nord Lead 2.
▼ If the Sys Ex data for a single Patch is sent using the “Dump One” command, it is considered being sent
from the Edit Buffer of the selected Slot. This means, that when the Patch is sent back to a Nord Lead 2, it
will not actually be stored, but temporarily placed in the Edit Buffer of its original Slot.
Byte Description
$F0 System Exclusive
$33 Manufacturer ID (clavia)
<Device ID> = Global MIDI Channel, 0-15
$04 Model ID for Nord Lead
<Message Type> See each type of message, below.
<Message Specification> See each type of message, below.
<Data 1> This and following bytes depend on the Message Type and Message
Specification. Some messages have no data bytes at all.
<Data 2>
<Data 3>
<etc.>
$F7 End Of Exclusive
