Page 40 Panel Reference
Modulation of FM Amount: Please note that the amount of FM can be modulated from the Mod Env and LFO
1, and also controlled manually from the Modulation wheel.
When Ring Modulation is activated, the FM Amount knob works as a Tune knob (see $). In this case, to
be able to control the FM Amount manually, you need to use the Modulation Wheel, with the modulation
destination set to FM.
Ring Mod
By pressing the Ring Mod/Sync button until the Ring Mod indicator lights, you activate Ring Modulation.
This is a function (also known as amplitude modulation), where the waveforms of the two oscillators are
multiplied. The result is a disharmonic sound, that is great for metallic or bell-like timbres.
When trying out Ring Modulation, make sure you listen to Oscillator 2, since it is mainly this that is af-
fected by the timbral changes!
Turning the Oscillator 2 Semitones knob will change the timbre, much as with FM. However, with Ring
Modulation, this will also affect the pitch of the sound! This means that activating Ring Modulation may
result in a sound with a completely different pitch than the “normal” sounds. To remedy this, you should
use the Ring Mod Tune knob:
When Ring Modulation is activated, the FM Amount knob works as a Tune knob with a range of roughly
one octave. To set the pitch to “normal”, turn off Ring Modulation and play a note, then activate Ring
Modulation, play the same note and adjust the Tune knob until the pitch is the same. Please note that the
pitch will change again if you change the timbre by adjusting the Semitones knob.
When Ring Modulation is activated, you cannot manually control the FM Amount, since that knob serves
as a Tune knob. Instead you can use the Modulation Wheel, with its destination set to FM.
Sync
By pressing the Ring Mod/Sync button until the Sync indicator lights, you activate Sync. In this mode,
Oscillator 2 is “synched” to Oscillator 1. This means that each time a period in Oscillator 1’s waveform
starts, Oscillator 2 is forced to start over with a new period, as well. See page 80 for a more in-depth ex-
planation.
The effect of this is that if Oscillator 2’s pitch is higher than Oscillator 1, its resultant waveform will have
a pitch determined by Oscillator 1, but a timbre depending on the pitch of Oscillator 2. See page 80 for
a basic explanation.
The easiest way to try this out is probably to activate Sync, and adjust the Tune setting for Oscillator 2
while holding down a note.
When trying out Sync, make sure you listen to Osc2, since it is this that is affected by the changes!
KBD TRACK
RING MOD
