Page 18 Basic Operations
Using a Control (Expression) Pedal
As indicated in the illustration on page 8, a regular expression pedal can be connected to the Control Ped-
al input, using a stereo cable. The connected pedal will either duplicate the Modulation wheel or inde-
pendently control one of a number of parameters. You can select different Control Pedal functions for
each of the four Program slots. Set it up as follows:
1. Hold down the Shift button, and press the “Special” button.
2. Press the Special button repeatedly, until the left character in the display is an “E” (for “Expression Pedal”).
3. Select a slot for which you want to set the pedal function by pressing one of the buttons A to D.
4. If you want the connected pedal to duplicate the functionality of the Modulation wheel, press the Program
Down button until the display shows “Eof”).
With this setting, the expression pedal will have the same function as the Modulation wheel.
5. If you instead want to select an independent control function for the pedal, press Store.
The display will flash, showing one of the abbreviations in the table below.
6. ‘Use the Program Up/Down buttons to select one of the following control functions:
7. After you have made your choice, press Store again.
You return to the “E” display.
8. Use the Program Up/Down buttons to select a control amount value (“1” to “7”).
This value (shown to the right in the display) determines the range of the pedal control signal. Lower
values give a smaller difference between the pedal’s “full up” and “full down” states. High values give a
big difference between the pedal’s up and down states.
Display shows: Pedal assigned to:
LFO 1 Amount.
LFO 2 Amount.
Filter Cutoff Frequency.
FM Amount.
Oscillator 2 Pitch.
STORE
