13
NILES AUDIO – 1-800-BUY-HIFI – 1-760-710-0992
CONNECTING THE LOUDSPEAKER IN ONE-SPEAKER STEREO MODE
(SI MODELS ONLY)
1. Strip two to three inches of each speaker cables’s outer jacket away from
the insulated conductors. Ensure that at least two inches of the separate
conductors are free. Do this on both loudspeaker connection cables.
2. Strip one half inch of insulation from the end of each conductor as show in
Figure 5 for both connection cables.
3. Choose the speaker cable that is labeled for the “Right” amplier channel.
Connect one stripped end of the “Right” speaker cable coming from the
amplier to the SI model’s connection cable’s red wire. To connect the two
wires, twist the stripped ends of the wire together and screw down the wire nut
on the twisted wires. The material inside the wire nut will protect the stripped
ends of the wire. However, if added protection is desired, place a large amount
of silicone sealant so the bottom of the wire nut is encased and sealed. Pay
attention to the markings on the speaker cable. Each loudspeaker you connect
must be connected to the amplier’s speaker wire in the same way.
4. Repeat step 3 with the connection cable’s black wire, that is in the same cable
as the wire attached in step 3, and the other stripped amplier “Right” speaker
cable’s conductor.
5. Repeat steps 3 and 4 for the “Left” speaker cable and the connection cable
with the “yellow/black” pair of conductors.
6. Make sure your amplier/receiver is turned OFF before making any
connections. Connect the opposite end of the speaker cable to the amplier
or receiver. Start by performing step 1 and 2 on the speaker cable near the
amplier. Pay attention to the markings on the speaker cable conductor.
Use the cable labeled “Right”and attach the same conductor you attached
to the red loudspeaker wire to the positive (red) or (+) “Right” amplier output
terminal. Attach the other conductor in that cable to the amplier’s “Right”
OFHBUJWFCMBDLPSmBNQMJàFSPVUQVUUFSNJOBM
7. Using the cable labeled “Left” attach the same conductor you attached to
the yellow loudspeaker wire to the positive (red) or (+) “Left” amplier output
terminal. Attach the other conductor in that cable to the amplier’s “Left”
OFHBUJWFCMBDLPSmBNQMJàFSPVUQVUUFSNJOBM
