niLes audio CorPoration – 1-800-buy-hiFi – 305-238-4373

CONNECTING ThE LOUdSpEAkER

  



  

  





  





  





Figure 11





NOTE: OBSERVE CORRECT POLARITY: POSITIVE

(+) GOES TO THE RED POST AND NEGATIVE

(–) GOES TO THE BLACK POST. IF YOU ARE

UNSURE OF WIRE POLARITY, SEE THE SECTION

CheCking LOudspeaker phase

ON THE NEXT PAGE.

  

Safety First



  Checking Loudspeaker Phase



  

  

NOTE: DO NOT USE ANY TOOLS FOR TIGHTENING. DOING SO MAY STRIP THE INSERT THREADS.

  

15

Figure 11. Loudspeaker wire

connections.

Left

Channel

Right

Channel
