Backlight
status
51
Function Querying Codes Return Codes
Power
supply
Speaker
Current
signal
source
Speaker
volume
D.Mode
Backlight
brightness
Sleep Mode
Status
7F 08 99 A2 B3 C4 02 FF 01 37 CF
7F 09 99 A2 B3 C4 02 FF 01 37 XX CF
NOTE:
● XX indicates the power on/off state.
● XX = 01: power on state
● XX = 00: power off state
NOTE:
● 01: mute
● 00: non-mute
7F 08 99 A2 B3 C4 02 FF 01 82 CF
7F 09 99 A2 B3 C4 02 FF 01 82 XX CF
7F 08 99 A2 B3 C4 02 FF 01 50 CF
7F 09 99 A2 B3 C4 02 FF 01 50 XX CF
NOTE:
● HDMI 1= 19
● HDMI 2= 1F
● HDMI 3= 1E
7F 08 99 A2 B3 C4 02 FF 01 33 CF
7F 09 99 A2 B3 C4 02 FF 01 33 XX CF
NOTE: XX indicates current volume value
(XX is a hexadecimal value, range: 00- 64).
For example, XX = 20 indicates current
volume value is 32 (decimal value),
XX = 00 indicates mute state.
7F 08 99 A2 B3 C4 02 FF 01 35 CF
7F 09 99 A2 B3 C4 02 FF 01 35 XX CF
NOTE: XX indicates the mode. 00-standard,
01-ECO mode,02-custom
7F 08 99 A2 B3 C4 02 FF 01 49 CF
7F 09 99 A2 B3 C4 02 FF 01 49 XX CF
NOTE: XX indicates the value of backlight
brightness (1 - 100), corresponding to the
hexadecimal number system (01 - 64).
7F 08 99 A2 B3 C4 02 FF 01 81 CF
7F 09 99 A2 B3 C4 02 FF 01 81 XX CF
NOTE:
● XX = 00 indicates the backlight is on.
● XX = 01 indicates the backlight is off.
7F 08 99 A2 B3 C4 02 FF 01 45 CF
7F 09 99 A2 B3 C4 02 FF 01 45 XX CF
NOTE:
● XX indicates the sleep wake up/sleep state.
● XX = 01: Sleep Mode Off state
● XX = 00: Sleep Mode On state
