93

www.neutrik.com

Center Contact:

Technical Specifications

Specifications

Rear Twist

®

& Rear Twist

®

Push Pull Bulkheads

Rear Twist Large Tiny & Cable

& Cable Jack Jack Tiny

Panel

Electrical

Mechanical

Cable anchoring Jacket crimping

zz

Neutrik

®

chuck principle N / A

Cable O.D. range mm 4.0 - 7.7 2.5 - 3.8 4.0 - 8.0 N / A

- Rear Twist Large 10.3 - - -

Center contact retention

>

30 N

zzz

-

Engagement force

<

25 N

zz<

20 N

z

Lifetime 1`000 mating cycles

z zzz

Environmental

Temperature range -30°C to +85°C

zz-

30°C to

+

40°C

z

Solderability Complies with IEC 68-2-20

zzz

N / A

Contact crimpability Complies with IEC 60803

zzzN / A

and IEC 60352-2

Materials

Shell: Brass (CuZn39Pb3), OPTALLOY coated

zzzz

PA6 (Push Pull only) N / A N / A

z

N / A

D-Shape housing: Zinc diecast (ZnAl4Cu1)

N / A N / A N / A z

gal Ni or black Cr plating

Ground contact:

Bronze (CuSn6), 0.2 µm AuCo over 2 µm NiP15

zzz

-

Brass (CuZn39Pb3), OPTALLOY coated - - -

z

Center contact:

Brass (CuZn35Pb2), 0.2 µm AuCo or

zzz

-

Brass (CuZn39Pb3), 0.2 µm AuCo - - -

z

Insulator: Teflon PTFE

zzzz

Chuck: Polyacetal POM N / A N / A

z

N / A

Insulation Shell: Polyacetal POM N / A N / A N / A

z

I.D. in mm Materials Plating Coding Ring (# of rings on base of contact)

0.4 Brass (CuZn39Pb3) 2 µm AuCo 0

0.5

zz

5

0.6

zz

1

0.7

zz

2

0.9

zz

3

1.1

zz

6

1.2

zz

4

1.7

zz

0

Impedance 75 7

z zzz

Rated voltage 500 V ac rms

z

250 V ac rms

zz

Insulation resistance

>

5 G7

z zzz

Dielectric withstanding voltage 1500 V ac rms

z

750 V ac rms

zz

VSWR / Return Loss b 1.050 /

>

32 dB up to 1 GHz

z

b 1.10 /

>

26 dB up to 1 GHz

z

b 1.03 /

>

37 dB up to 1 GHz

b 1.065 /

>

30 dB up to 2 GHz

z

b 1.14 /

>

24 dB up to 2 GHz

z

b 1.05 /

>

32 dB up to 2 GHz

b 1.100 /

>

26 dB up to 3 GHz

z

b 1.22 /

>

20 dB up to 3 GHz

z

b 1.08 /

>

28 dB up to 3 GHz

Inner contact resistance b 3 m7 (initial)

z zzz

Outer contact resistance b 2 m7 (initial)

z zzz
