48
look for the logo
RCA Series
Specification
Profi
®
Phono Socket
Accessories
Rated current per contact: 16 A rms continuous
zz
Rated insulation voltage: 50 V ac
zz
Contact resistance:
>
100 G
7
<
5 G
7
Dielectric strength: 1500 V dc 500 V dc
Capacitance (pin to shell): 7 pf 9 pf
Life time
(
mating cycles
)
:
>
5000
zz
Cable O.D. range: 3.0 - 7.3 mm
z
-
Wiring: soldering
zz
Max. wire size : 2.5 m
2
/ 14 AWG
z
-
Cable anchoring:
Neutrik
®
chuck type strain relief z
-
Solderability: complies with IEC 68-2-20
zz
Housing: Brass (CuZn39Pb3)
z
-
Zinc diecast (ZnAICu1) -
z
Insert: PBTP 20% GR
z
-
Contacts: Brass (CuZn39Pb3)
zz
Contact plating: 5 µm Au plated over 5 µm Ni
zz
Chuck: Polyacetal (POM)
z
-
Temperature range: -30°C to +80°C
zz
Protection class: IP 40
zz
Flammability: UL 94 HB
zz
Phono (RCA) Socket
NF2D-* Chassis Phono (RCA) socket in D Shape housing
NF2D-B-* Chassis Phono (RCA) socket in black D Shape housing
* color coding: 0 - Black, 1- Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Grey, 9 - White
Ordering Information
Phono Profi
®
NF2C-B2 Professional "phono Plug" (RCA or CINCH type), two plugs with red and black coding, two strain relief
chucks for a second cable diameter
Electrical
Mechanical
Material
Environment
NDP Dummy plug for phone socket
SCL Plastic sealing cover to protect the connector sockets against dust and moisture
SCDX Hinged cover seals D-size chassis connectors, IP54 rated
