19
NC5FAV-SW NC5MAV-SW
NC5FAV-SW
NC3FD-H NC3MD-V
NC3FD-V / NC3FD-H
NC3MD-V / NC3MD-H
NC5MBV-SW
L
A and B Series 5 pole connector with additional switch
L
Normally open, normally closed (NO - NC) contact
L
Switch activated by mating XLR cable connector
L
Available in 5 pole, 3 or 4 pole on request
L
"D" Shape metal shell
L
Optimal RF protection using 3 shield contacts
L
Horizontal and vertical PCB mount with separate
ground contact
L
Mounting holes with M3 threads available
L
2 piece connector, insert is removable from shell
L
Front locked / unlocked insert
L
Special version with screw termination
Inserting (Schematic):
XLR Chassis Connectors
A/B Series 5-pole switch D Series
Incorporated switch Insert removable
www.neutrik.com
