132
NPPA Series Configuration* Wiring Grounding
NPPA-TT-PT** 2 x 48 jacks half normalled bottom 288 push terminals individual
NPPA-TT-PT-FN** 2 x 48 jacks full normalled 288 push terminals individual
NPPA-TT-PT-HNT** 2 x 48 jacks half normalled top row 288 push terminals individual
NPPA-TT-PT-I** 2 x 48 jacks isolated 288 push terminals individual
NPPA-TT-PT-P** 2 x 48 jacks parallel 288 push terminals individual
NPPA-TT-S** 2 x 48 jacks half normalled bottom 288 solder terminals individual
NPPA-TT-S-FN** 2 x 48 jacks full normalled 288 solder terminals individual
NPPA-TT-S-HNT** 2 x 48 jacks half normalled top row 288 solder terminals individual
NPPA-TT-S-I** 2 x 48 jacks isolated 288 solder terminals individual
NPPA-TT-S-P** 2 x 48 jacks parallel 288 solder terminals individual
NPPA-TT-PT-PH 2 x 48 jacks half normalled bottom 288 Phoenix push terminals individual
NPPA-TT-SD50 2 x 48 jacks half normalled bottom 4 x 50 pole D-SUB groups of 12 channels
NPPA-TT-SD25 2 x 25 jacks half normalled bottom 10 x 25 pole D-SUB groups of 12 channels
NPPA-TT-E56 2 x 48 jacks half normalled bottom 6 x 56 pole ELCO male connectors individual
NPPA-TT48-E56 2 x 24 jacks half normalled bottom 3 x 56 pole ELCO male connectors individual
NPPA-TT-E90 2 x 48 jacks half normalled bottom 4 x 90 pole ELCO male connectors individual
NPPA-TT-IDC 2 x 48 jacks programmable by jumpers 288 IDC terminals (KRONE-Type) individual
* fully loaded jack pairs only, to built patch panels with mixed configuration use pre-config jackpairs
** in case of need added normalling bars can be used to reconfigure up to 4 jackpairs
Pre-configured Jack-Pairs
NJ3TTA-4-HNB blocks of 2 channels half normalled bottom row cover ident color: clear
NJ3TTA-4-HNT blocks of 2 channels half normalled top row cover ident color: yellow
NJ3TTA-4-FN blocks of 2 channels full normalled cover ident color: green
NJ3TTA-4-P blocks of 2 channels parallel cover ident color: red
NJ3TTA-4-I blocks of 2 channels isolated cover ident color: orange
Accessories
NPPA-S Strain Relief bar
NPP-TB Series Configuration Wiring
NPP-TB 2 x 24 TB (BP0316/MIL-P-642/2) jacks programmable for all commonly used configurations push terminals
NPP-TB-HN 2 x 24 TB (BP0316/MIL-P-642/2) jacks half Normalled Bottom Row solder tags
Accessories
NPP-LB-**
Channel identification and status plates, pack of 100 per color, 9 different colors
NPP-C Metal dust cover
NPP-S A second rear extention bar for fix the very large cables.
NKTB* Patch cord with NP3TB plugs. Available in black and red. Length: 30, 40, 60, 90 cm
**: 0 - Black, 1- Brown, 2 - Red, 3 - Orange, 4 - Yellow, 5 - Green, 6 - Blue, 7 - Violet, 8 - Grey, 9 - White; Must be ordered in multiples of 100.
NYS SPPL
NYS-SPP-L1 1/4" Patch Panel, 2 x 24 channels, configuration half normalled, isolated, split
NYS-SPCR1 Send / Return module (Split Print)
Ordering Information
Part Number Description
look for the logo
