Ordering Information
D Shape Adapters
Circular Adapters
Part No. Port 1 Port 2 Comments
NA2FBNC 3 pole XLR female BNC socket
1)
NA2FP 3 pole XLR female TS
2)
,1/4" plug
1)
NA2FPMF 3 pole XLR female RCA / phono socket
1)
NA2FPMM 3 pole XLR female RCA / phono plug
1)
NA2MBNC 3 pole XLR male BNC socket
1)
NA2MP 3 pole XLR male TS
2)
,1/4" plug
1)
NA2MPMF 3 pole XLR male RCA / phono socket
1)
NA2MPMM 3 pole XLR male RCA / phono plug
1)
NA3FF 3 pole XLR female 3 pole XLR female gender conversion adapter
NA3FF-B 3 pole XLR female 3 pole XLR female gender conversion, black plating
NA3FJ 3 pole XLR female TRS
2)
,1/4" jack locking jack
NA3FM 3 pole XLR female 3 pole XLR male extention adapter
NA3FMX 3 pole XLR female 3 pole XLR male contacts 2 - 3 inverted
NA3FP 3 pole XLR female TRS
2)
, 1/4" plug
NA3JJ stereo 1/4" jack TRS
2)
, 1/4" jack extension adapter, locking jack
NA3MJ 3 pole XLR male TRS
2)
, 1/4" jack locking jack
NA3MM 3 pole XLR male 3 pole XLR male gender conversion adapter
NA3MM-B 3 pole XLR male 3 pole XLR male gender conversion, black plating
NA3MP 3 pole XLR male TRS
2)
,1/4" plug
NA4FC-F Speakon
®
NL4FC 3 pole XLR female speaker adapter
3)
NA4FC-M Speakon
®
NL4FC 3 pole XLR male speaker adapter
3)
NA4LJX Speakon
®
NL4FX TS
2)
, 1/4" jack speaker adapter
3)
NA4MP-F Speakon
®
NL4MP 3 pole XLR female speaker adapter
3)
NA4MP-J Speakon
®
NL4MP TS
2)
, 1/4" jack speaker adapter
3)
NA4MP-M Speakon
®
NL4MP 3 pole XLR male speaker adapter
3)
NA4MP-M-X Speakon
®
NL4MP Speakon
®
NL4MP speaker adapter 1+ / 1- inverted
3)
NA5FF-B 5 pole XLR female 5 pole XLR female gender conversion adapter, black plating
NA5MM-B 5 pole XLR male 5 pole XLR male gender conversion adapter, black plating
NA2BBNC-D4B BNC socket RCA / phono socket colour coded yellow
NA2BBNC-D9B BNC socket RCA / phono socket colour coded white
NA2F-D0B-TX 3 pole XLR female RCA / phono socket colour coded black
4)
NA2F-D2B-TX 3 pole XLR female RCA / phono socket colour coded red
4)
NA2F-J-TX 3 pole XLR female 1/4" jack ground lifted
4)
NA2M-D0B-TX 3 pole XLR male RCA / phono socket colour coded black
4)
NA2M-D2B-TX 3 pole XLR male RCA / phono socket colour coded red
4)
NA2M-J-TX 3 pole XLR male 1/4" jack ground lifted
4)
NE8FF EtherCon
®
EtherCon
®
RJ45 coupler
NL4MMX 4 pole Speakon
®
4 pole Speakon
®
lockable coupler
NL8MM 8 pole Speakon
®
8 pole Speakon
®
lockable coupler
1)
... Wired according to IEC 268-12: pin 2 = signal, pin 1 and 3: connected to ground
2)
... TRS-Tip, Ring, Sleeve contact (stereo); TS-Tip, Sleeve contact (mono)
3)
... Detailed wiring info on www.neutrik.com
4)
... Unbalanced / balanced line conversion, 1:1 transformer 200 7 : 200 7
