Je bekijkt pagina 11 van 143
1
2
7
6
5
3
4
Figure 1. Orbi router front (left figure) and back (right figure) views
1. Router LED: Use the LED on the front of the router to determine its status. For more
information about the LED behavior, see Orbi router LED behavior on page 12.
2. Sync button: Use the Sync button to connect a WPS device to the router. For more
information, see WiFi connection using WPS on page 24.
3. Reset button: Use the Reset button to restart (reboot) the router or reset the router
to its factory default settings:
•
Restart the router: Press the Reset button for less than five seconds. The Power
LED lights solid amber and the router restarts.
•
Reset the router to its factory default settings: Press and hold the Reset button
until the Power LED starts blinking amber. The router resets and returns to its
factory settings.
4. 2.5G Multi-Gigabit LAN ports 1–3: These Ethernet ports provide a wired connection
speed of up to 2.5 Gigabit Ethernet (2.5GbE). You can connect a LAN device to each
of the three ports, each of which support speeds up to 2.5 Gbps. You can also connect
these ports to a 2.5 Gigabit Ethernet (2.5GbE) port on each satellite to create a wired
backhaul connection. For more information, see Set up your satellite with a wired
connection to your router on page 19.
User Manual11Overview and Setup
Whole Home Tri-Band Mesh WiFi 7 System
