Basic 802.1Q VLAN: If you do not need custom tagging on a port, and you do
not need a voice VLAN, you can use the basic 802.1Q VLAN mode. When you
enable basic 802.1Q VLAN mode, VLAN 1 is added to the switch and all ports
are assigned as access members of VLAN 1. A port that functions in access mode
can belong to a single VLAN only, and does not tag the traffic that it processes.
You can assign access ports to different VLANs, or change a port to trunk mode
so that it automatically belongs to all VLANs on the switch and tags the traffic that
it processes.
ā
Advanced 802.1Q VLAN: If you need custom tagging on a port, or want to set
up a voice VLAN, you must use advanced 802.1Q VLAN mode. When you enable
advanced 802.1Q VLAN mode, VLAN 1 is added to the switch and all ports are
assigned as untagged members of VLAN 1. You can tag or untag ports, remove
ports, add more VLANs, assign ports to different VLANs, and manage port PVIDs.
You can also set up a voice VLAN.
The following table provides an overview of VLAN features that are supported on the
switch.
Table 3. Supported VLAN modes for the GS105EP and GS105EPP
Advanced
802.1Q VLAN
Basic
802.1Q VLAN
Advanced
Port-Based VLAN
Basic
Port-Based VLAN
VLAN Feature
64555Total number of
VLANs
YesYes (trunk port only)NoNoEgress tagging
YesYes (trunk port only)YesNoMultiple VLANs on a
single port
YesNoNoNoVoice VLAN
Table 4. Supported VLAN modes for the GS108EP and GS108EPP
Advanced
802.1Q VLAN
Basic
802.1Q VLAN
Advanced
Port-Based VLAN
Basic
Port-Based VLAN
VLAN Feature
64888Total number of
VLANs
YesYes (trunk port only)NoNoEgress tagging
YesYes (trunk port only)YesNoMultiple VLANs on a
single port
YesNoNoNoVoice VLAN
User Manual37Use VLANS for Traffic
Segmentation
Gigabit Ethernet Easy Smart Managed Switches
