7
reduce the risk of fire, electric shock, personal injury and will reduce the
installation time of the appliance.
This equipment may be used by children of at least 8 years of age and by
people with reduced physical and mental capabilities and lack of familiarity
with the equipment, if supervision or instruction is provided on how to use
the equipment safely so that the associated risks are understood. Children
should not play with the equipment. Unsupervised children should not
carry out cleaning or maintenance of the equipment.
The unit is used for occasional indoor operation.
SAFETY RULES
• The unit must not be used outdoors in damp weather, in bathrooms
or other wet or humid environments.
• Please note that the appliance can become very hot. Therefore, the
appliance should be placed at a safe distance of at least 1 metre (3
feet) from flammable objects such as: furniture, curtains, etc.
• Do not cover the unit with, for example, a towel.
• The appliance must not be located directly under a wall socket.
• The appliance must not be connected to the mains via a timer or
programmable switch.
• The appliance must not be placed in rooms where flammable dusts,
liquids or gases are used or present.
• If the appliance is connected by means of an extension cord, ensure
that the extension cord is as short as possible and fully extended
and of the correct cross-section.
• The unit should not be used in the immediate vicinity of a bath,
shower or swimming pool.
• If the power supply cable is damaged, it must be replaced by the
manufacturer, its representative, service or a qualified person in
order to avoid danger.
• Do not connect other devices to the same mains socket to which the
device is connected.
• The appliance should not be left unattended. Keep children and pets
away from the appliance.
• Do not place the unit on unstable, moving surfaces or where the unit
can be knocked over.
• If the appliance is not used for a long time, unplug it from the power
supply. Do not leave the appliance switched on unattended. When
disconnecting the appliance from the mains, pull out the plug, never
pull on the power cord.
• Keep the unit away from curtains, curtains or places where the air
inlet is easily blocked.
• To prevent possible electric shock, never operate the appliance with
wet hands or when there is water on the power cord.
• Do not dispose of electrical appliances with unsorted municipal
waste, use separate collection points. Contact your local authorities
for information on available collection systems. If electrical
appliances are disposed of in landfill sites, hazardous substances
can seep into the groundwater and enter the food chain, damaging
your health.
• This equipment is not intended for use by persons (including
children) with reduced physical or mental capabilities or without
experience unless supervision or instruction is provided regarding
the safe use of the equipment so that the associated risks are
understood.
• Children should be supervised to ensure that they do not play with
the appliance.
• Do not modify or repair the appliance yourself. To do so, send it to
a service centre or qualified electrician (during the post-warranty
period).
PICTOGRAMS AND WARNINGS
Read the operating instructions, observe the warnings and safety
conditions contained therein!
The device may need to be fitted
Do not touch the hot surface
Do not cover
Disconnect from power supply before repair or maintenance
For indoor use
Protect from moisture
Keep out of reach of children
Do not dispose of with household waste
Recyclable
DESCRIPTION OF THE GRAPHIC ELEMENTS
The numbering below refers to the components of the device
shown on the graphic pages of this manual.
Designation
Description
1
Main transport handle
2
Control knob / switch
3
Heating elements
4
Swivel base
5
Additional transport handle
6
Ventilation openings
* There may be differences between the graphic and the actual product
PURPOSE
This product is intended for home and office use only and not for industrial
or other commercial use. Use only with a power cord that is undamaged
and in good condition, which meets the applicable standards and
regulations. The heater must be supplied from the mains power supply,
the parameters of which are specified in the rating table. Do not include
other additional appliances on the same circuit as the heater in operation.
The appliance has 3 heating levels and the possibility of slow rotation.
OPERATION OF THE DEVICE
MONTAGE
Before using the heater, it must be assembled; check the unit and the
power cable for damage beforehand.
• To facilitate installation, place the unit on a horizontal, flat and stable
surface.
• Unscrew the nuts located in the lower oval part of the radiator.
• Pass the power cable through the hole in the centre of the base and
assemble the circular bottom of the unit, placing it in the body of the
base.
• Insert the nuts through the base and screw the unit to the base with
them, as shown in Fig. C2.
SWITCHING ON THE DEVICE
The heater is activated by means of the on/off switch / knob, fig. A2. The
power and heating mode selection positions are located on the right and
left side of the switch knob.
On the left are the heating power modes along with the rotation of the
heater:
Fig. B5 - 400W heating power
Figure B6 - 800W heating power
fig. B7 - 1200W heating power
To the right are the heating power modes without heater rotation:
Fig. B2 - 400W heating power
Fig. B3 - 800W heating power
fig. B4 - 1200W heating power
Switch Fig. A2 in position Fig. B1 switches the unit off.
SECURITY
• The radiator is fitted with a safety mechanism that disconnects the
power supply if the radiator is tilted or overturned. The control button
for this mechanism is located on the underside of the heater fig. C1.
• ATTENTION It is strongly recommended not to use the button while
the unit is in operation.
• The appliance has a safety system that automatically switches off
the heater if it overheats. In the event of overheating, switch off the
heater and allow it to cool down and remove the plug from the socket
for at least 10 minutes. Then put the plug back in the socket and
switch the heater on. If the same fault mentioned above still occurs,
remove the plug from the socket and return the appliance for service.
USE OF THE HEATER:
Always operate the heater in an upright position, following all instructions
and recommendations listed in this manual
HEATER LOCATION:
Place the heater in the coldest part of the room.
HEATER CONNECTION:
Plug the heater directly into a wall socket. Make sure that the plug fits
tightly into the socket. A loose connection can cause overheating and
damage to the plug.
