Regulacja temperatury w

pomieszczeniu z wykrywaniem

otwartego okna

[nie]

Z regulacją na odległość

[nie]

Z adaptacyjną regulacją startu

[nie]

Z ograniczeniem czasu pracy

[nie]

Z czujnikiem ciepła promieniowania

[nie]

Dane kontaktowe

Grupa Topex Sp. z o. o. Sp. k. Ul. Pograniczna 2/4, 02-285 Warszawa

Podsumowanie:

W przypadku miejscowych elektrycznych ogrzewaczy pomieszczeń zmierzona sezonowa efektywność energetyczna ogrzewania pomieszczeń

ηs nie może być gorsza niż wartość deklarowana nominalnej mocy cieplnej urządzenia.

TRANSLATION OF THE ORIGINAL INSTRUCTION

90-062 / 90-063 / 90-064

NOTE: BEFORE THE EQUIPMENT IS USED FOR THE FIRST TIME, READ THIS INSTRUCTION MANUAL AND KEEP IT FOR FUTURE

REFERENCE. PEOPLE WHO HAVE NOT READ THIS INSTRUCTION SHOULD NOT ASSEMBLE, LIGHT, ADJUST OR OPERATE THE UNIT

DETAILED SAFETY REGULATIONS

ATTENTION!

Read carefully-The infrared heater is designed for safe operation. Nevertheless, installation, maintenance and operation of the heater can be

dangerous. Observing the following procedures will reduce the risk of fire, electric shock, injury to person and keep installation time to a minimums.

1.1 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack

of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

1.2 WARNING: In order to avoid overheating, do not cover the heater.

1.3 Children of less than 3 years should be kept away unless continuously supervised.

1.4 Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended

normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved.Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

1.5 CAUTION-some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable

people are present.

2. Introduction

2.1 Depending on the power cord type his fan heater may be used only in household, warehouses and workshops, building sites or greenhouses

depending. It incorporates a thermostat and a self-resetting thermal cut-out to control the heating elements. The thermostat feels the air temperature

and controls the surrounding temperature. The fan motor is controlled by thermostat and it stops when the thermostat cuts off the heating element.

The self-resetting thermal cut-out will switch off the heater to ensure the safety when overheating.

3. Technical specifications

Model

90-062

90-063

90-064

Voltage

220-240V

380-400V 3~

required power

2000W

3000W

5000W

current

8.3-9.1A

12.5A-13.6A

7.2-7.6A

Required Fuse

10A

16A

10A

Setting

25/1000/2000W

25/1500/3000W

50/3300/5000 W

Self-resetting Thermostat

65°C

85°C

75°C

Size of heater ( mm)

210*160*217

265*210*290

300x235x345

N.W.( KG)

1.7

2.85

4.32

3.1 Housing of steel plate and coated by heat-resistant powder .

3.2 Supplied complete with cord and plug .

4. Description of Control Panel

90-062

90-063

90-064

4.1 Left Knob : selector with heat setting

the device is turned off

fan on
