EN
TRANSLATION (USER) MANUAL
Puller with separator and actuator : 11-847
NOTE: BEFORE USING THE EQUIPMENT, PLEASE READ THIS
MANUAL CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
PERSONS WHO HAVE NOT READ THE INSTRUCTIONS SHOULD
NOT CARRY OUT ASSEMBLY, ADJUSTMENT OR OPERATION OF
THE EQUIPMENT.
SPECIFIC SAFETY PROVISIONS
NOTE!
Read the operating instructions carefully, follow the warnings and safety
conditions contained therein. The appliance has been designed for safe
operation. Nevertheless: installation, maintenance and operation of the
appliance can be dangerous. Following the following procedures will
reduce the risk of injury and will shorten the installation time of the
appliance.
SAFETY RULES
The puller must be assembled according to the instructions before use, all
nuts correctly tightened. Extensions must not be used on the hydraulic
cylinder arm. The device is designed so that hand strength is sufficient.
The component to be dismantled must be firmly clamped in a vice or other
holding device. The puller should only be used for components such as
bearings etc. which have been installed by fitting. Always check that the
puller is correctly assembled and positioned perpendicular to the
workpiece.
DO NOT use damaged or worn tools. Inspect them before each use.
DO NOT heat the jaws of the puller while the gear wheel or bearing is
being heated, as this will harden the jaws and thus affect their strength.
DO NOT hit the workpiece or actuator with a hammer if the workpiece
cannot be removed despite applying maximum puller force. Use a more
powerful puller.
IMPORTANT: Always refer to the vehicle manufacturer's service
instructions or owner's manual to determine the correct method of
servicing according to the procedures and parameters specified. This
service manual is for guidance only.
Purpose
The actuator with separator is designed for the removal of bearings, gears
and other components that were fixed by a tight fit.
Pictograms and warnings
1. Read the instructions carefully
2. Requires assembly
3. Use personal protective equipment eye protection
4. Use personal protective equipment hand protection
5. Protect from children
6. Do not throw in with household waste
Description of graphic elements
The following numbering refers to the components of the device
shown on the graphic pages of this manual.
Designation
Description
1
Separator
2
Hydraulic cylinder
3
Beam
4
Threaded main bars (male on both sides) with nuts
5
Threaded main bars (male/female)
6
Cylinder extension 85mm
7
Cylinder extension 55mm
* There may be differences between the graphic and the actual
product
METHOD OF APPLICATION
MONTAGE
Installation sequence of the components
Open the packaging, check that all kit components are in the case.
NOTE: Depending on the necessary length of the puller, the main bars
should be installed in a different order.
Single main bar
• The assembly of the separator starts by screwing the actuator fig. A1
into the threaded hole fig. B17 in the beam fig. A3. Assembly is the
same for both cases fig. C1.
• Screw the main rod, fig. A4, with the shorter threaded section, fig. B4,
into the holes of the separator, fig. B3; correctly fitted rods are shown
in fig. C2.
• Then unscrew the nuts and remove the washers fig. B13 the beam
slots fig. B12 over the ends of the main bracket fig. A4. Then secure
the whole with washers and nuts fig. B13.
• Place the actuator extension fig. A6 or fig. A7 on the end of the fig. B7
actuator. The set is ready for operation.
Extended bar
• Screw the main rod, fig. A5, with a section with internal thread, fig. B5,
into the holes of the separator, fig. B3; correctly fitted rods are shown
in fig. D1.
• Screw the main rod fig. A4, with the shorter threaded section fig. B4
into the holes of the extension rod fig. B14, correctly fitted rods are
shown in fig. D2.
• Then unscrew the nuts and remove the washers fig. B13 the beam
slots fig. B12 over the ends of the main bracket fig. A4. Then secure
the whole with washers and nuts fig. B13.
• Place the actuator extension fig. A6 or fig. A7 on the end of the fig. B7
actuator. The set is ready for operation.
ATTENTION: It is imperative that the order of the main bars is maintained,
if the order is confused it will not be possible to safely install the beam with
the actuator.
Kit contents:
• Separator with actuator - 9 elements
• Transport case
• Operating instructions
Rated data
Parameter
Value
Range of bearing diameters
supported
ø75 - 105 mm
Max squeeze depth
420 mm
Actuator power
10 t
Mass
7.9 kg
ENVIRONMENTAL PROTECTION
The product should not be thrown away with household waste, but
should be disposed of at suitable facilities. A non-recycled product is a
potential danger to the environment and human health.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "Grupa Topex") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including, among
others. Its text, photographs, diagrams, drawings, as well as its composition, belong
exclusively to Grupa Topex and are subject to legal protection under the Act of 4 February
1994 on Copyright and Related Rights (Journal of Laws 2006 No. 90 Poz. 631, as
amended). Copying, processing, publishing, modifying for commercial purposes the entire
Manual and its individual elements, without the consent of Grupa Topex expressed in
writing, is strictly prohibited and may result in civil and criminal liability.
