2
neo-tools.com
INSTRUCTION MANUAL
OF ADJUSTABLE JACKS
11-750, 11-751
IMPORTANT: READ THE INSTRUCTIONS CAREFULLY BEROFE USE!
TECHNICAL DATA Technical data are subject to change without notice.
MODEL CAPACITY (KG) MIN. HIGH MAX. HIGH
11-750 3000 295 mm 428 mm
11-751 2000 275 mm 420 mm
IMPORTANT INFORMATION REGARDING SAFETY
Read the following safety information before rst use of adjustable jacks.
ATTENTION!
The following warnings must be obeyed or otherwise the supported vehicle may fall, the adjustable
jacks may become damaged, personal injuries or property damage may occur.
ATTENTION!
Jacks must not be loaded with a load exceeding their carrying capacity.
Overloading may result in damaging the jacks.
THE LOAD SHOULD BE APPLIED IN THE MIDDLE OF THE JACK HEAD. THE JACKS MUST ALWAYS BE USED
IN PAIRS. THEY MUST BE POSITIONED ON A HARD, EVEN SURFACE, CAPABLE OF CARRYING THE PRESSURE
RESULTING FROM LOAD. USE OF JACKS ON AN INSUFFICIENTLY HARD SURFACE MAY CAUSE THEIR
INSTABILITY, AND FALLING OF SUPPORTED VEHICLE.
USE OF JACKS
1. When lifting the vehicle, obey the recommendations contained in the vehicle instruction. Jacks may be
placed only in locations indicated by the vehicle manufacturer.
2. Place the jacks under the vehicle in places indicated by the vehicle manufacturer.
3. Set appropriate height by turning the catch pawl arm upwards, slide outwards the jack stem with head to
the required height. Next press the pawl arm down to engage the pawl catch into a notch in the jack stem.
MAKE SURE THAT THE PAWL CATCH IS ENGAGED FULLY AND SECURELY WITH THE STEM.
4. Carefully lower the vehicle, resting it on jacks.
CHECKING THE JACKS
1. Before each use the jacks must be carefully inspected visually to determine that there are no visible cracks,
cracking welds or missing elements. In case of a suspicion that a jack may be damaged, it must not be
used any more.
2. DUE TO A DANGER RELATED TO IMPROPER USE OF JACKS OF THIS TYPE, THE USER MUST NOT
INTRODUCE ANY CHANGE IN THEIR DESIGN.
Grupa Topex Sp z o.o. Spółka Komandytowa, Warszawa ul. Pograniczna 2/4
