9 VSE212.V2-09 2X adaptor ø10mm tubing with male 5/8"-18 to m16x1.5 With 'o' ring ttings.

10 VSE212.V2-10 2X adaptor female m16x1.5 To female 5/8"-18unf.

11 VSE212.V2-11 2X adaptor female m14x1.5 To ø3/8" tube tting.

12 VSE212.V2-12 2X adaptor female m16x1.5 To ø3/8" tube tting.

13 VSE212.V2-13 2X adaptor male m14x1.5 With 'o' ring to ø3/8" tube tting

14 VSE212.V2-14 2X adaptor male m16x1.5 With 'o' ring to ø10mm tube tting

15 VSE212.V2-15 Adaptor for izuzu i-tec systems.

16 VSE212.V2-16 Quick connect manifold with ø1/14"- 5/16" tube ttings

17 VSE212.V2-17 Adaptor male m12x1.5 To male m10x1.0With 'o' ring for mercedes benz applications

18 VSE.212.V2-18 Adaptor male m12x1.5 To female m10x1.0 For ford/volkswagen 16v applications

19 VSE212.V2-19 Adaptor male m12x1.5 To female m8x1.0 For bmw applications

20 VSE212.V2-20 2X adaptor male m12x1.5 To male m8x1.0 With 'o' ring for mercedes benz, vw golf & bmw applications

21 VSE212.V2-21 Adaptor quick connect to m12x1.25 Banjo tting with nylotron

22 VSE212.V2-22 Adaptor quick connect to m12x1.5 Banjo tting with brass washers

23 VSE212.V2-23 Adapter quick connect to m10x1.0 Banjo ttings for triumph applications

24 VSE212.V2-24 Adapter quick connect to m8x1.0 Banjo tting with brass washers for toyota applications.

25 VSE212.V2-25 Adaptor quick connect to male m6x1.0 With 'o' ring for suzuki applications

26 VSE212.V2-26 Adaptor quick connect to1/4" tubing barb for bosch mono jetronic applications

27 VSE212.V2-27 Adaptor male m12x1.5 To male m8x1.0 With 'o' ring for audi secondary adaptor applications.

28 VSE212.V2-28 2X m14x1.5 Male adaptor.

29 VSE212.V2-29 M14x1.5 Male adaptor.

30 VSE212.V2-30 M14x1.5 Female adaptor

31 VSE212.V2-31 Case

4. GENERAL INFORMATION

Because fuel systems and access points are so varied, it is impractical to list all of the applications. Always refer to a reliable workshop manual, or the car

manufacturer for the recommended test procedure and access points before commencing any work on fuel injection systems.

There are two basic types of fuel injection systems. Port fuel injection (p) (g.A) uses separate injectors to supply the fuel to each cylinder. Throttle body

injection (tbi) (g.B) injects fuel from a position above the throttle plate on the intake manifold. On both systems there is a supply side, which brings fuel to

the injectors, and a return side which brings unused fuel back to the tank.

5. BASIC PORT FUEL INJECTION (PFI) SYSTEM

Fig. A

1 Pulse Dampener

2 Test Port (schrader Valve)

3 Manifold Vacuum Hose Connection

4 Pressure Regulator

5 Fuel Injectors

6 Flexible Hose

7 Fuel Return Line

8 Fuel Pressure Line

9 In-line Fuel Filter

10 Fuel Tank

11 In-tank Fuel Pump

12 Pump Inlet Filter

13 Pulsator

14 Fuel Cap

6. BASIC THROTTLE BODY INJECTION (TBI) SYSTEM.

Fig.B

1 tbi unit fuel injectors

2 throttle body pressure regulator

3 fuel return line

4 exible hose

5 fuel pressure line

6 in-line fuel lter

7 fuel tank

8 in-tank fuel pump

9 pump inlet lter

10 fuel cap
