8
Inflation
Connect the suction hose (10) to the blow-off connector (9).
SUCTION NOZZLES
➢ The wide nozzle (12) is used for vacuuming solids and liquids on
medium to large surfaces.
➢ The crevice nozzle (16) is specially designed for cleaning crevices
and edges.
ADAPTER
The included adapter (23) can be used to connect the suction hose (10)
to the power tool. To do this, mount it between the suction hose and the
hoover socket on the power tool.
The adapter is compatible with most power tools that have a circular
waste ejection opening: sawdust, dust, etc.
ON AND OFF
Plug the plug into an outlet. To switch on the hoover switch (2) :
Switch position 0: Off.
Switch position I: Normal operation
Switch position II: Automatic mode
DRY VACUUMING
For dry vacuuming, use the HEPA filter (21), the dirt paper bag (14) and
the fabric pre-filter (24)
WET VACUUMING
For wet vacuuming, use the foam filter (15)
Always check that the filter is securely fastened.
The telescopic suction tube (11) can be attached to the suction hose (10)
to extend it.
WATER DRAIN VALVE
To make it easier to empty the tank (7) after wet vacuuming, it is equipped
with a water drain valve (18). Unscrew the water drain valve (18) by
turning it counterclockwise and drain the liquid.
NOTE
During wet vacuuming, the floating safety switch (5) closes when
the maximum level in the tank is reached. In this case, the suction
noise of the appliance will change and become louder.
The unit should then be switched off and the tank emptied.
Important!
The wet and dry hoover is not suitable for vacuuming flammable liquids.
Use only the supplied foam filter for wet vacuuming.
NADMUCH
Connect the suction hose (10) to the blow-off connector (9) of the
hoover.
CLEANING, MAINTENANCE
NOTE
Always pull the power plug out of the socket before cleaning.
Cleaning
➢ All safety devices, vents and the motor housing should be kept free
of dirt and dust as far as possible.
➢ We recommend cleaning the device immediately after use.
Push & Clean cleaning
Automatic filter cleaning:
➢ Block the hose inlet (10)
➢ Press and release the Push & Clean button (19)
Cleaning the machine head
Clean the appliance regularly with a damp cloth and mild soap. Do not
use cleaning agents or solvents; these can be aggressive to the plastic
parts of the unit.
Tank cleaning (7)
The container can be cleaned with a damp cloth and mild soap or under
running water, depending on the amount of dirt.
Cleaning the Hepa filter (21)
Clean the Hepa filter (21) regularly by carefully patting it down and
cleaning it with a soft brush or hand brush.
Cleaning the foam filter (15)
Clean the foam filter (15) with a small amount of soft soap under running
water and allow to dry.
Cleaning the fabric pre-filter (22)
The fabric pre-filter (22) should be cleaned by gently tapping or
brushing away dirt. Cleaning should not be carried out in living areas. If
the filter is very dirty, use a mild soap and water solution to wash the
reusable bag and rinse it with clean water. Allow the wet filter to air dry
for 24 hours before installing it in the tank.
POWER TOOL SOCKET (AUTOMATIC MODE)
This is a useful socket when you are using a power tool, such as a saw,
grinder, etc., for which a hoover is required for the dust generated
during operation.
Important! Do not use a power tool with a higher wattage than
permitted, see the maximum permitted wattage label on the socket.
➢ Connect the power cord of the power tool to the automatic socket
(22) and connect the suction hose (10) to the hoover connector on
the power tool. Check that the connections are secure and tight.
➢ The supplied power tool adapter (23) can be used to connect the
suction hose (10) to the power tool. To do this, mount it between the
suction hose and the hoover socket on the power tool.
➢ Set the switch (2) on the wet and dry hoover to position II of the
automatic mode. When the power tool is switched on, the wet/dry
hoover will also switch on. When the power tool is switched off, the
wet and dry hoover will switch off after the set delay.
TECHNICAL DATA
Hoover 1600W 04-739
Parameter
Value
Supply voltage
230 V AC
Supply frequency
50 Hz
Rated motor power
1600 W
Maximum power of additional device
1800 W
Total tank capacity
35 L
Suction hose length
1,5-4,5 m
Suction hose diameter
35 mm
Length of supply cable
4m
Protection class of the device
I
Degree of protection
IP X4
Mass
7.46 kg
Year of production
2023
04-739 indicates both the type and the designation of the machine
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with
household waste, but should be taken to appropriate facilities for
disposal. Contact your product dealer or local authority for information
on disposal. Waste electrical and electronic equipment contains
environmentally inert substances. Equipment that is not recycled
poses a potential risk to the environment and human health.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "Grupa Topex") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including, among
others. Its text, photographs, diagrams, drawings, as well as its composition, belong
exclusively to Grupa Topex and are subject to legal protection under the Act of 4 February
1994 on Copyright and Related Rights (Journal of Laws 2006 No. 90 Poz. 631, as
amended). Copying, processing, publishing, modification for commercial purposes of the
entire Manual and its individual elements, without the consent of Grupa Topex expressed
in writing, is strictly prohibited and may result in civil and criminal liability.
DE
ÜBERSETZUNG (BENUTZERHANDBUCH)
HOOVER
04-739
WICHTIGER HINWEIS: LESEN SIE DIESES HANDBUCH VOR DER
VERWENDUNG DES ELEKTROWERKZEUGS SORGFÄLTIG DURCH
UND BEWAHREN SIE ES ZUM SPÄTEREN NACHSCHLAGEN AUF.
Hinweis: Dieses Gerät kann von Kindern im Alter von mindestens 8
Jahren und von Personen mit eingeschränkten körperlichen und
geistigen Fähigkeiten sowie mangelnder Erfahrung und Vertrautheit
mit dem Gerät verwendet werden, wenn eine Beaufsichtigung oder
Einweisung in die sichere Verwendung des Geräts erfolgt und die
damit verbundenen Risiken verstanden werden. Kinder sollten nicht
mit dem Gerät spielen. Unbeaufsichtigte Kinder sollten keine
Reinigungs- und Wartungsarbeiten an den Geräten durchführen.
SPEZIFISCHE SICHERHEITSVORSCHRIFTEN:
➢ Bevor Sie den Staubsauger an das Stromnetz anschließen,
vergewissern Sie sich immer, dass die Netzspannung mit der auf
dem Typenschild des Geräts angegebenen Spannung
übereinstimmt.
➢ Nicht in einer Umgebung verwenden, in der Entzündungs- oder
Explosionsgefahr besteht.
➢ Die Inspektion und Wartung muss bei ausgeschaltetem und von der
Stromquelle getrenntem Gerät durchgeführt werden.
➢ Bei Verwendung motorisierter Saugdüsen:
➢ nicht zur Wasserentnahme verwenden.
➢ zur Reinigung nicht in Wasser eintauchen
