Je bekijkt pagina 5 van 24
90-001
PARAMETR
SYMBOL
WARTOŚĆ
Napięcie zasilania
V
230V
Częstotliwość zasilania
f
50Hz
Maksymalne natężenie przepływu
wentylatora
F
51.74 m3/min
Moc wentylatora
P
50 W
Wartość eksploatacyjna
SV
1.22 (m3/min)/W
Pobór mocy w trybie czuwania
P
SB
0 W
Poziom mocy akustycznej
wentylatora
L
WA
60.31 dB(A)
Maksymalna prędkość powietrza
c
3.15 m/s
Klasa ochronności
II
Norma dla pomiaru wartości
eksploatacyjnej
Rozporządzenie Komisji (UE)
206/2012 z dnia 6 marca 2012 r
Dodatkowych informacji udziela
Grupa Topex Sp. z o. o. Sp. k.
ul. Pograniczna 2/4, 02-285
Warszawa
EN
INSTRUCTION MANUAL
STAND & TABLE FAN 40 CM
90-001
NOTE: BEFORE THE EQUIPMENT IS USED FOR THE FIRST TIME, READ
THIS INSTRUCTION MANUAL AND KEEP IT FOR FUTURE REFERENCE.
DETAILED SAFETY REGULATIONS
a) This equipment may be used by children at least 8 years old and by
persons with reduced physical and mental abilities and persons
who are not familiar with the equipment, if supervision or
instruction regarding the use of the equipment in a safe manner is
provided so that the threats were understandable. Children should
not play with the equipment. Unattended children should not clean
or maintain the equipment.
b) Before removing the cover, make sure that the fan is disconnected
from the power supply.
WARNING! The device is used for indoor work.
Warning:
1. Do not insert your fingers or other objects into the grille or movable
parts when the fan is running.
2. Do not place the fan near window curtains or on uneven floors.
3. Avoid places with gas, gasoline and those that threaten the fan
getting wet.
4. In the event of unusual noises or other irregularities in operation,
immediately remove from use and return the fan to the manufacturer
or an authorized repair service.
5. If the supply cord is damaged, it has to be replaced by the
manufacturer, service representative or similarly qualified person in
order to avoid threats.
6. Do not attempt to disassemble or repair the fan in case of its incorrect
work. Send the fan to an authorized service center for repair.
7. This fan is not intended for use by people (including children) with
reduced physical, sensory or mental capabilities or lack of experience
and knowledge unless they have been given supervision or
instruction concerning use of the fan by a person responsible for
their safety.
8. Children should be supervised so that they can not play with the fan.
9. After assembling the fan, do not remove the grille.
10. Disconnect the fan from the power source before cleaning or
maintenance. It it is necessary to remove the grille for cleaning or
maintenance, make sure that the fan propeller does not move and
fan has been disconnected from power source.
11. Replacement of a part of a safe suspension system should be
entrusted to the manufacturer, his service representative or a person
with appropriate qualifications.
12. Fastening to the wall, e.g. through hooks and other means, should
withstand four times the weight of the wall fan.
13. Attaching the suspension system should be entrusted to the
manufacturer, his service representative or a person with
appropriate qualifications.
WARNING: If suspicious oscillation is visible, immediately turn off the fan
and do not use it, contact the manufacturer, his service representative or
a suitably qualified person.
Maintenance :
1. Unplug the fan from the socket.
2. Remove dust from the outside of the fan with a soft cloth.
3. To remove the front grille, unscrew the securing screws located on
the edge of the grill.
4. Wipe dust off the grilles and blades with a soft cloth. Note - Do not
wet the cloth too much so that it does not form dripping drops, it
may limit the fan insulation.
5. When cleaning the blades, do not use too much force, deformation
of the blade will affect the balance.
6. The fan should be assembled in reverse order to removal. If this is not
possible, do not use force. Send the fan to the manufacturer or a
designated service center as soon as possible to check the device.
7. Before start, the propeller guard must be tightened securely with the
mounting screws.
8. Run for 5 minutes. Check that the fan is working properly.
Maintenance is complete.
Explanation of the pictograms used
1
2
3
4
1. Read the operating manual, observe the warnings and safety
conditions contained in it!
2. Second protection class.
3. Disconnect the device before repair.
4. Protect the device against moisture
PARTS NAME
1. Front Grill
2. Grill ring
3. Blade Lock Nut
4. Blade
5. Grill Lock Nut
6. Back Grill
7. Motor
8. Front Motor Cover
9. Motor Cover
10. Oscillation Button
11. Motor Holder
12. Connection Holder
13. Fixed Screw#1
14. SS Holder#1
15. Fixed Screw#2
16. SS Holder#2
17. Base
18. Gasket
19. Fixed Screw
20. Power cord
ASSEMBLY INSTRUCTION
1. Take all of the appliance parts out of the packaging and remove all
packaging materials and inserts.
2. Insert the SS Holder #2 (16) into the Base (17), and tighten up by the
Gasket (18) and Fixed Screw (19)
3. Connect SS Holder#1 to SS Holder#2(16) , and tighten up by Fixed
Screw#2(15)
4. Connect Motor Holder to SS Holder#1(14), and tighten up by Fixed
Screw#1(13)
5. Take the back grill (6), put it on the motor (7), and fixed by grill lock
nut (5)
6. Take the blade (4), put it into the motor (7), and fixed by blade lock
nut (3)
7. Take the front grill (1), put it to match the back grill (6). And fixed by
Grill ring(2)
OPERATION INSTRUCTION
• There’s 3 speed to select.
1 – Low speed 3 – High speed
2 – Mid speed 0 – It’s the power off button to stop
