Nelson Wireless TWIG System
Project Planning Form
Obtain a Site/System Map
Number of Valves:
Number of TWIGs:
TWIG-1:
TWIG-2:
TWIG-4:
Number of Controllers (TD200):__________110V AC, ___________12V DC
Identify Site Constraints
Elevation:
Vegetation/Crop type and height:
Buildings:
Antenna interference:
Indentify Controller Locations
Power (AC or Solar):
Antenna mounting:
Length of cable between controller and antenna (<50’):
Antenna support structure:
Evaluate TWIG Locations
Elevation above ground level:
Mounting (On Valve/Remote):
Solenoid mounting (On Valve/TWIG):
Valve Series: 800 Series Metal, 1000 Series Plastic
Damage Risk (tractors, livestock, etc.):
Identify Repeater Locations (if necessary)
Power (AC or Solar):
Antenna mounting:
Length of cable between Repeater box and antenna (<50’):
Antenna support structure:
Hydraulic Protection Installed
Pressure Relief (Required): Y/N
Air Relief: Y/N
VFD: Y/N
Other Control Accessories needed?
Contact-TWIG: 110V AC, 12V DC, 'D' Cell batteries
Master valve control: Solenoid Power: 24V AC or 12V DC Latch
Flow meter:
Pause Event Sensor or Switch:
Connect to Other Controller:
