848 Airport Road, Walla Walla, Washington 99362 U.S.A.
Tel: +1 509.525.7660 / Fax: +1 509.525.7907
nelsonirrigation.com
40 41
Practice Exercise #3 — Create a cooling cycle ‘Program’.
Goal is to setup a program that will to do frequent short irrigation cycles.
Project details: You want to cool fruit by running the system for 10 minutes on and 30 minutes off.
Make the programs continuously repeat. How would you do the program and set the equal time for
4 valves?
Solution:
Rotate dial to “PROGRAM” and make 4 ‘GROUPs’. Make
each group set for 10 minutes then change the program
to ‘READY’ after setting the cycles to +++ for continuous.
The program will start when the right dial is rotated to
‘RUN’. It will repeat continuously until the dial is rotated
from ‘RUN’.
Practice Exercise #4 — Create programs that each have only one
valve in it then setup to run each valve separately. Goal is to run each valve
as a program to give individual control.
Project details: Consider that your elds are scattered so you need to give irrigation instructions to
the irrigator by phone. The irrigator is at the TD200 when you tell him what to do. His experience
level is to only change time but not do a lot with the controller. You want to run each valve a specic
length of time. How would you do it?
Solution:
Previously you would have made a program for each valve. When you want to run a valve you have
the irrigator run the program. You explain to simply turn to the ‘ADJUST’ dial position, select the
program, press the right arrow to ‘READY’ and press ENTER. Your program will start shortly to run
the valve for each program.
A photo of a Nelson system used for frequent
on/off cooling in an orchard of fruit trees.
A good way to handle valves
scattered over a big area.
